Dino-Lite AM4115-FIT

Name: Dino-Lite AM4115-FIT
Brand: Dino-Lite
SKU: AM4115-FIT
Price: 589 EUR
Availability: InStock

589,00 €

Excl. 19% VAT , excl. Shipping Cost

Article

AM4115-FIT

Fabricant Nr.

AM4115-FIT

Das AM4115-FIT hat eine besondere Beleuchtung mit LED IR-Licht im 850 nm Spektrum. Das AM4115-FIT hat eine besondere Beleuchtung mit LED IR-Licht im 850nm Spektrum.Die Dino-Lite Edge Modelle bieten aufgrund des anpassbaren Kappen-Designs eine überlegene Bildqualität und hervorragende Flexibilität. » Auch verfügbar mit ~780nm/ 940nm LEDs (Modell AM4115-FKT/FJT).

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Les images sont fournies à titre de référence et peuvent ne pas être exactes, le produit réel peut différer.

Fréquemment achetés ensemble

Cet article: Dino-Lite AM4115-FIT
589,00 €
Excl. 19% VAT , excl. Shipping Cost
Dino-Lite EarScope Pneumatic
1 168,83 €
Excl. 19% VAT , excl. Shipping Cost
Dino-Lite AM3715TB
489,00 €
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

Weitere Informationen

Dino-Lite range:	Dino-Lite Special lighting

Lighting

Light/ LED type:	~850 nm Infrared
Number of LEDs:	8
LED on/off switchable:	Yes
Infrared filter:	IR pass filter
Diffuser available:	No
Emission filter:	No
Polarizer:	No

Optics

Magnification:	20-220x
Macro zoom:	No
Working distance:	Standard
Lens type:	Glass with anti-reflection coating

Sensor

Sensor type:	CMOS
Resolution:	1.3 Megapixel (1280x1024)
Maximum frame rate:	30 fps

Compatibility

Interface:	USB 2.0
Operating system:	Windows 7, 8 & 10, MacOS 10.9 and up
Included software:	DinoCapture 2.0 (Windows), DinoXcope (Mac OS)
Supported image formats (Windows):	BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
Supported video formats (Windows):	WMV, FLV, SWF
Supported image formats (MacOS):	JPEG, PNG
Supported video formats (MacOS):	MOV
Imaging standards:	DirectShow, UVC

Housing

Housing material:	Composite/ plastic housing
Magnification lock:	Yes
Dimensions:	10.5cm (L) x 3.2cm (D)
Weight:	105g
Cable length:	1.8m

Features

Special feature:	No
Measurement:	Yes
Calibration:	Yes
Microtouch sensor:	Yes
ESD safe:	No

Information

Package contents:

Microscope, Carry pouch, Software CD, Calibration target, User manual

Warranty information:

2 years European warranty

Regulatory approval:

CE, FCC, ROHS

Price range:

€350,00 - €550,00

Working distance/ field of view/ depth of field:

Magnification Rate	Working Distance	Field of View(x)	Field of View(y)	Depth of Field
Listed values may differ slightly					Unit = mm
20	60.2	19.5	15.6	2.5
30	33.5	13.0	10.4	1.8
40	20.9	9.8	7.8	1.5
50	13.9	7.8	6.3	-
60	9.7	6.5	5.2	-
70	7.1	5.6	4.5	1.0
80	5.5	4.9	3.9	-
90	4.5	4.3	3.5	-
100	4.1	3.9	3.1	-
110	4.0	3.6	2.8	-
120	4.1	3.3	2.6	-
130	4.5	3.0	2.4	-
140	5.0	2.8	2.2	-
150	5.6	2.6	2.1	-
160	6.3	2.4	2	-
170	7.1	2.3	1.8	-
180	8.0	2.2	1.7	-
190	8.9	2.1	1.6	-
200	9.9	2.0	1.6	-
210	10.9	1.9	1.5	-
220	11.9	1.8	1.4	-

Special Light:

Information

Plus d’information
Version	TEC
Fabricant Nr.	AM4115-FIT
Fabricant	Dino-Lite
Pays d'origine	Taïwan
EAN	4712805475681
Poids	0.105000
Taille	M
Numéro de tarif douanier	90119090
