The HQ 5/H lift transfer unit transfers WT 5 workpiece carriers pneumatically between a longitudinal conveyor line and a transverse line. The transverse transport level is 4.5 mm above the longitudinal level, and the protective cover can be removed even at low conveying heights. Air supply: 5 to 6 bar via a 6 mm push-in connector.
Lift Transfer Unit HQ 5/H for WT 5 Workpiece Carriers - Bosch Rexroth 3842998854
BOSCH REXROTH
Original product
Net price (excl. VAT)
€6,399.07
Item
BRR-3842998854
Manufacturer no.
3842998854
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.3842998854
Country of originGermany
Customs tariff number84313900
ConditionNew
Article
BRR-3842998854
Frequently Bought Together
-
This Item:
€6,399.07
-
Carrying Plate WT 5, Aluminum, 845 x 845 mm, 19.05 mm - Bosch Rexroth 3842545270
€1,217.91
-
Communication Module 8400MotEC PROFINET - Bosch Rexroth 3842553450
€708.79
Total price
The HQ 5/H lift transfer unit is a pre-assembled module for the VarioFlow transfer system, designed to divert WT 5 workpiece carriers from the main longitudinal line into a transverse line, or to merge them back. The transverse transport level sits 4.5 mm above the longitudinal line by design, and the protective cover can be fully removed even at minimal conveying heights, simplifying maintenance access.
- Compatible with all WT 5 workpiece carriers
- Pneumatic lift drive, 5 to 6 bar, 6 mm push-in connection
- Longitudinal track width (bL): 455 mm, 650 mm or 845 mm
- Transverse track width (bQ): 455 mm, 650 mm, 845 mm or 1040 mm
- Roller pitch (p): 130 mm, 195 mm, 260 mm or 325 mm
- Nominal conveying speed: 6, 9 or 12 m/min
- Transfer direction: left, right or both sides
- Motor connection: cable/connector (S) or terminal box (K)
- Roller material: galvanized steel or nitrocarburized steel
- Supplied pre-assembled, including line unit ST 5/XH or ST 5/H
Technical data
| Parameter | Value |
|---|---|
| Article number | 3842998854 |
| Type | Lift transfer unit HQ 5/H |
| Delivery state | Pre-assembled |
| Scope of supply | Incl. line unit ST 5/XH or ST 5/H |
| Compatible workpiece carriers | WT 5 (all types) |
| Transverse transport level | 4.5 mm above longitudinal line level |
| Air supply pressure | 5 to 6 bar |
| Pneumatic push-in connection | 6 mm |
| Longitudinal track width bL | 455 / 650 / 845 mm |
| Transverse track width bQ | 455 / 650 / 845 / 1040 mm |
| Roller pitch p | 130 / 195 / 260 / 325 mm |
| Nominal speed vN | 6 / 9 / 12 m/min |
| Transfer direction (OFD) | Left (1) / Right (2) / Both sides (3) |
| Drive shaft side, main line (DSM) | Left (1) / Right (2) |
| Motor connection (AT) | Cable/connector (S) or terminal box (K) |
| Roller material (TR) | Galvanized steel (1) or nitrocarburized steel (2) |
| Protective cover (SC) | Without (1) or with (2) |
| Weight | approx. 0.01 kg (individual component; system weight depends on configuration) |
| ESD version | TEC |
|---|---|
| Manufacturer Nr. | 3842998854 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.009900 |
| HS-Code | 84313900 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
