Starlight - LED illumination for microscopy and machine vision

Precise LED illumination for microscopy, inspection and industrial imaging

Starlight develops LED illumination for microscopy and machine vision. The range covers ring lights, UV and IR illumination, cold light sources and complete microscope stands for incident and transmitted light - matched to inspection, testing and imaging.

Whether you need fluorescence excitation with UV at 365 nm and 405 nm, homogeneous illumination from the RL12 ring lights, or glare-free cold light through a light guide, the products are designed for reproducible contrast and defined working distances. We supply Starlight for laboratories, quality control and production.

💡LED technologyLong-life LED illumination with stable colour temperature and low heat generation.

✅Reproducible contrastDefined working distances and even illumination for repeatable inspection results.

🔬Built for microscopyRing lights, stands and cold light sources for incident and transmitted light.

📦Available from stockAdvice and sourcing of the full Starlight range from a single supplier.

Selection

Starlight best sellers

View all products ->

LED Ring Light UV 365 nm and IR, working distance 90 mm - 180 mm - Starlight RL12-18 UV365 View product ->

LED Ring Light UV 365 nm and IR, working distance 45 mm - 260 mm - Starlight RL12-25 UV365 View product ->

LED Ring Light 24V UV (365 nm), working distance 45 mm - 260 mm - Starlight RL12-25-24V UV365 View product ->

LED Ring Light 24V, UV (365 nm), 12 LEDs, outer Ø 130 mm - Starlight RL12-18-24V UV365 View product ->

LED Cold Light Source 6900 K, 1500 lm, 15 mm light-guide port, UK plug - Starlight LED.70 [UK] View product ->

LED Cold Light Source 6900 K, 1500 lm, 15 mm light-guide port, CH plug - Starlight LED.70 [CH] View product ->

Microscope Stand MSL2 with transmitted and incident light (without LED modules), 200 lm, 5700 K - Starlight MSL2 View product ->

Microscope Stand with Transmitted and Ring Light (NW), clamping diameter up to 66 mm - Starlight MSL3-66 NW View product ->

Range

The Starlight product lines

View category ->

RL12 ring lights 26 products LED ring lights with different working distances for even illumination. UV and IR illumination 1 products UV excitation at 365 nm and 405 nm plus IR for fluorescence and special contrast. Cold light sources LED.70 13 products LED cold light sources with light-guide port for glare-free, cold light.

Popular

RL12 ring lights

View category ->

LED Segment Ring Light blue 470 nm, working distance 45-260 mm, 12 LEDs - Starlight RL12-25s-S40 B View product ->

LED Segment Ring Light blue 470 nm, 12 LEDs, working distance 150 mm - 500 mm - Starlight Segment-Ringlicht RL12-10s-S40 B View product ->

LED Segment Ring Light green 528 nm, working distance 90-180 mm, outer Ø 130 mm - Starlight RL12-18s-S40 G View product ->

LED Segment Ring Light amber 590 nm, working distance 90-180 mm, outer Ø 130 mm - Starlight RL12-18s-S40 A View product ->

LED Segment Ring Light amber 590 nm, 12 LEDs, working distance 150 mm - 500 mm - Starlight Segment-Ringlicht RL12-10s-S40 A View product ->

LED Segment Ring Light red 625 nm, working distance 50-800 mm, outer Ø 130 mm - Starlight RL12-18f-S40 R View product ->

LED Segment Ring Light red 625 nm, working distance 150-500 mm, outer Ø 130 mm - Starlight RL12-10s-S40 R View product ->

LED Segment Ring Light green 528 nm, working distance 50-800 mm, outer Ø 130 mm - Starlight RL12-18f-S40 G View product ->

Buyer's guide

Choosing the right Starlight illumination

Ring light by working distance

The RL12 ring lights differ mainly in their usable working distance. Pick the model so your object sits within the stated range:

Short distance for compact setups and higher magnification.
Medium to long distance for more clearance above the part.

Spectrum: white, UV or IR

White light is enough for standard inspection. For fluorescence or material contrast, use UV at 365 nm or 405 nm; IR content helps with specific tasks. When working with UV, always use suitable eye and skin protection.

Ring light or cold light source

Ring lights mount at the lens and give near shadow-free illumination. Cold light sources such as the LED.70 feed light through a light guide and suit flexible, spot illumination with no heat load on the object.

Complete with a stand

The MSL stands combine incident and transmitted light with a matching ring light. Check the maximum clamping diameter so your microscope head is held securely.

Comparison

Which Starlight line fits?

Criterion	RL12 ring lights	Cold light sources LED.70	Microscope stands MSL
Design	Ring light at the lens	Source with light guide	Stand with integrated light
Light type	White, UV, IR	Cold white via light guide	Incident and transmitted, ring light
Typical use	Inspection, machine vision	Flexible, spot illumination	Stereo microscopy in the lab
Working distance	Selectable by model	Guided via light guide	Defined by the stand
Heat load	Low	Very low at the object	Low
Mounting	At lens or holder	Separate housing	Ready-to-use complete system

Good to know

Starlight at a glance

LEDLED technology throughout illumination and stands

UV/IRExcitation at 365 nm and 405 nm plus IR

MicroscopyRing lights and stands for incident and transmitted light

Machine visionIllumination for inspection and imaging

FAQ

Frequently asked questions about Starlight

What is Starlight illumination used for?

Starlight manufactures LED illumination for microscopy and industrial machine vision. This includes ring lights, UV and IR illumination, cold light sources and microscope stands for inspection, testing and imaging.

What does UV 365 nm or 405 nm mean on the ring lights?

These values give the wavelength of the ultraviolet light. UV at 365 nm and 405 nm excites fluorescence and reveals contrast that stays hidden under white light. When using UV, suitable eye and skin protection is required.

How do the RL12 ring lights differ?

The RL12 models differ mainly in their usable working distance and LED configuration. You choose the model so your object is evenly illuminated within the stated distance range.

What is the advantage of a cold light source such as the LED.70?

The LED.70 feeds light through a light guide, separating the source from the object. This gives cold, glare-free light with no significant heat load and allows flexible, spot illumination.

Are the MSL microscope stands ready to use?

The MSL stands combine incident and transmitted light with a ring light in one setup. The key figure is the maximum clamping diameter, which determines which microscope head can be mounted. Some variants are supplied without LED modules.

Need advice or a trade quote?

We help you select the right Starlight illumination and prepare a quotation for your project.
