Warmbier - ESD protection and ESD measurement technology
Wolfgang Warmbier is a German manufacturer and system supplier for electrostatic discharge (ESD) protection in electronics manufacturing. The focus is on ESD measurement and testing: high-resistance meters, charged plate monitors, ionizer testers and complete measuring and verification kits for the ongoing monitoring of an ESD protected area (EPA).
The range is rounded out by dissipative equipment such as ESD floor coverings, polyester films, separating underlays and accessories. This allows an EPA to be set up in line with IEC 61340-5-1 and, just as importantly, to be verified continuously by measurement - Made in Germany.
Warmbier Bestsellers
Charged plate monitor analog - Warmbier CPM 74
View product ->
Warmbier 5235.DPF.100. DPF-100 ESD polyester film, 1220 mmx100 m
View product ->
Warmbier 5235.DPF.SK100. DPF-SK-100 ESD polyester film - self-adhesive, 1220 mmx100 m
View product ->
ESD high-resistance meter measuring kit digital - Warmbier Metriso 3000
View product ->
ESD high-resistance meter kit with electrodes digital - Warmbier Metriso 3000
View product ->
ESD walking test kit WT5000 with USB and evaluation software - Warmbier WL32131
View product ->
Separating underlay for ESD floor covering, roll 2.0 m x 35 m, vapour-tight - Warmbier WL31877
View product ->
Ionizing blower Aerostat PC2, benchtop model with heater - Warmbier WL74027
View product ->
Warmbier product areas
ESD measurement / high-resistance meters
ESD verification kit with case - Warmbier SRM 200
View product ->
ESD floor covering Ecostat PR-2.0 PVC roll material, grey, 9000 x 2000 x 2 mm - Warmbier WL47417
View product ->
ESD audit case without equipment for Metriso 3000/B530 in aluminium - Warmbier WL32139
View product ->
ESD backrest electrode Model 900 for leakage resistance on ESD chairs - Warmbier WL35434
View product ->
ESD surface resistance meter with data memory - Warmbier SRM 200
View product ->
Ecostat-DF POLYCAN WL 2 dissipative floor sealant, 10 kg, light grey - Warmbier WL20088
View product ->
Comfort Plus Supertec ESD high chair, grey, with glides, seat height 610 to 850 mm - Warmbier 1710.KSP.ST
View product ->
ESD turning electrode Model 890 in case for multiple resistance measurements - Warmbier WL32136
View product ->
Choosing the right Warmbier ESD equipment
Measure or monitor?
For one-off or periodic testing of resistances (floor, bench, wrist strap), high-resistance meters such as the Metriso 3000 or the Metriso B530 basic kit are the right choice. For continuous verification of ionizers, use charged plate monitors and ionizer testers instead.
Which test kit?
- Metriso measuring kits: resistance and dissipation measurement per IEC 61340-5-1, with electrodes and case.
- Walking test kit: assessment of the person-shoe-floor system including evaluation software.
- Verification kit (SRM 200): fast on-site checks in the EPA.
Set up and prove the EPA
Dissipative floor coverings (Ecostat), separating underlays and ESD polyester films form the basic equipment of the protected area. The matching measurement technology then documents that the required limit values are being met.
Which ESD test for what?
| Criterion | Resistance measurement | Walking test | Charged plate monitor |
|---|---|---|---|
| Measured quantity | Resistance to ground / dissipation | Person-shoe-floor system | Discharge time / offset voltage |
| Typical device | Metriso 3000 / B530 | Walking test kit WT5000 | CPM 74 / CPM35 |
| Test object | Floor, bench, wrist strap | Person wearing ESD footwear | Ionizer / discharge |
| Result | Resistance in ohms | Pass/fail with readings | Discharge time and offset voltage |
| Use | Setup and periodic testing | Personnel qualification | Ionizer verification |
| Reference | IEC 61340-5-1 | IEC 61340-4-5 | IEC 61340-4-7 |
Warmbier at a glance
Frequently asked questions about Warmbier
What does the Warmbier brand stand for?
Wolfgang Warmbier is a German manufacturer of products for electrostatic discharge (ESD) protection. The range focuses on ESD measurement and testing technology as well as dissipative equipment for electronics manufacturing.
What is an ESD high-resistance meter like the Metriso 3000?
A high-resistance meter measures very high resistances, from the kilohm range up to the teraohm range. It is used to determine and document the resistance to ground and dissipation of ESD floors, work surfaces and personnel equipment in line with IEC 61340-5-1.
What does a charged plate monitor do?
A charged plate monitor (CPM) tests ionizers by charging a defined metal plate and measuring the discharge time and the residual (offset) voltage. This verifies whether an ionizer neutralises static charges reliably and in a balanced way.
What is an ESD walking test kit used for?
A walking test evaluates the combined system of person, ESD footwear and floor. As the person walks, the body voltage that occurs is measured and compared with limit values to prove that people in the EPA are adequately grounded.
Are Warmbier products suitable for building an EPA per IEC 61340-5-1?
Yes. Warmbier supplies both the dissipative base equipment such as floor coverings, films and separating underlays, and the measurement technology and test kits needed to set up an ESD protected area (EPA) and verify its limit values by measurement.
Need advice or a project price?
Planning an ESD protected area or looking for the right measurement technology? We advise you on Warmbier instruments and equipment and prepare a project quotation for you.
