Component processing
Industrial technology
Component processing on esd.equipment covers devices and tools for the mechanical preparation of electronic components before placement: cutting and forming machines for axially and radially taped parts, depaneling systems for separating PCB panels, and Iteco specialist solutions for Superform, Dies-Tooling, motors, sealers and component counting. Machines from Burst&Zick, Ebso and Schleuniger cover wire diameters from 0.3 to 1.5 mm for radial and axial cutting and forming operations.
DepanelingDepaneling machines for assembled PCBs
Punching toolsDies and tooling for separation and punching
Superform forming toolsSuperform component forming and cutting systems
Drive motorsDrive motors and replacement drives
Sealing devicesBag and film sealers
Component countingComponent counting systems for SMD reels
| Manufacturer | Model | Type | Wire diameter |
|---|---|---|---|
| Burst&Zick | C 034/S | Cut & form axial | 1.4 mm |
| Burst&Zick | C 053 | Cut radial | 1.0 mm |
| Burst&Zick | C 055 PF | Cut radial | 1.1 mm |
| Burst&Zick | C 057 | Cut radial | 1.5 mm |
| Burst&Zick | C 066 MA | Cut radial, motor drive | 0.8 mm |
| Ebso | 10509 | Bend & cut axial | 0.3-0.8 mm |
Typical applications: Preparation of axially and radially taped components for THT placement (cutting and forming machines), panel singulation after reflow soldering (depaneling), component counting and kitting in the warehouse (component counting, sealers), and repair and servicing of component processing machines (Schleuniger spare parts).
