The HQ 5/XH lift transfer unit transfers WT 5 pallets between main and branch conveyor lines in linked assembly systems. The transfer level sits 4.5 mm above the main-line transport level, ensuring a smooth, jam-free transition. A 6 mm push-in pneumatic connection at 5 to 6 bar and a removable protective cover make installation and maintenance straightforward.
Lift Transfer Unit HQ 5/XH for WT 5 Pallet Transport - Bosch Rexroth 3842998855
BOSCH REXROTH
Original product
Net price (excl. VAT)
€6,524.75
Item
BRR-3842998855
Manufacturer no.
3842998855
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.3842998855
Country of originGermany
Customs tariff number84313900
ConditionNew
Article
BRR-3842998855
Frequently Bought Together
-
This Item:
€6,524.75
-
End Plate AB 5-OC Active Side, Anodized Aluminum - Bosch Rexroth 3842559589
€105.22
-
Mounting Kit for ID 40/SLK Read-Write Head, Longitudinal Transport, B 650/845 - Bosch Rexroth 3842545142
€37.85
Total price
The HQ 5/XH is a pneumatically actuated lift transfer unit for the Bosch Rexroth TS 5 assembly conveyor system. It handles controlled infeed and outfeed of WT 5 workpiece carriers, enabling flexible cross-transfer within linked assembly lines.
- Compatible with all WT 5 workpiece carriers - no additional adapters required
- Transfer level 4.5 mm above the main-line level - smooth pallet transition, no jamming
- Protective cover removable even at low conveyor heights - simplifies maintenance and reconfiguration
- Pneumatic push-in connection, 6 mm, at 5 to 6 bar - connects directly to standard shop-floor air supply
- Track widths for longitudinal and cross transport (bL / bQ) freely combinable: 455, 650, 845 mm (bQ also 1040 mm)
- Roller pitch (p) selectable: 130, 195, 260 or 325 mm
- Nominal speed 6, 9 or 12 m/min; motor connection as cable/plug (S) or terminal box (K)
- Outfeed direction left, right or both sides (OFD 1/2/3); king-shaft mounting left or right (DSM 1/2)
- Rollers in zinc-plated steel (TR 1) or nitrocarburised steel (TR 2); optional protective covers (SC 2)
Technical data
| Parameter | Value |
|---|---|
| Article number | 3842998855 |
| Type | Lift transfer unit HQ 5/XH |
| Delivery condition | Unassembled (HQ 5/H is delivered assembled) |
| Scope of supply | Lift transfer unit HQ 5/XH (without track unit) |
| Compatible workpiece carriers | WT 5 (all variants) |
| Longitudinal track width bL (mm) | 455 / 650 / 845 |
| Cross track width bQ (mm) | 455 / 650 / 845 / 1040 |
| Roller pitch p (mm) | 130 / 195 / 260 / 325 |
| Nominal speed vN (m/min) | 6 / 9 / 12 |
| Compressed air supply (bar) | 5 ... 6 |
| Pneumatic push-in connection | 6 mm |
| Height offset cross vs. main line | +4.5 mm |
| Motor connection | Cable/plug (S) or terminal box (K) |
| King-shaft mounting | Left (1) or right (2) |
| Outfeed direction | Left (1), right (2) or both sides (3) |
| Roller material | Zinc-plated steel (TR 1) or nitrocarburised steel (TR 2) |
| Protective cover | Without (SC 1) or with (SC 2) |
| Weight | approx. 0.01 kg (order unit; total weight depends on configuration) |
| ESD version | TEC |
|---|---|
| Manufacturer Nr. | 3842998855 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.009900 |
| HS-Code | 84313900 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
