Festo MS4-LFM-1/4-AUV (535768) Micro Filter

Festo
€9,889.00
Excl. 19% VAT , excl. Shipping Cost
Article
FES-535768

Manufacturer Nr.
MS4-LFM-1/4-AUV
Micro Filter
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price
Model series MS
size 4
Construction set up Fibre filter
Filter porosity [µm] 0,01
Condensate drain Fully automatic
Operating pressure [bar] 2 to 12
Operating medium Compressed air to ISO 8573-1:2010 [6:8:4]
Inert gases
Air purity class at the output Compressed air to ISO 8573-1:2010 [1:7:2]
Max. normal flow for air purity class [l/min] 360
Min. normal flow for air unit class [l/min] 54
Filter effective degree [%] 99,9999
Max. condensate amount [ml] 25
Clamp protection Integrated as metal bowl
Corrosion resistant class KBK 2 - moderate corrosion stress
Food compatibility See expanded material information
Medium temperature [°C] 5 to 60
ambient temperature [°C] 5 to 60
Bearing temperature [°C] -10 to 60
Residual oil content [mg/m³] 0,01
Fastening type pipe installation
With Accessories
Selectively:
installation position vertical ± 5°
Pneumatic connection 1 G1/4
Pneumatic connection 2 G1/4
Housing material Aluminium die casting
Filter material Borosilicate fibre
Clamps material Aluminium die casting
Aluminium wrought alloy
Seals material NBR
Material information Copper and PTFE-free
RoHs compliant
Product weight [g] 350
Window material PA
More Information
Manufacturer Nr. MS4-LFM-1/4-AUV
Manufacturer Festo
EAN 4052568169398
Weight 0.440000
HS-Code 84213925
GPSR manufacturer information Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity Original product
Condition of article New
