Function-integrated aluminium profile for routing cables and hoses within the profile cross-section of 120x120 mm assembly systems. The two-part design (profile and hinged cover) provides a concealed 10 mm groove for socket strips, plus mounting points for grounding and potential equalizer cables. Cut to any length from 100 mm to 6070 mm.
Cable Management Profile 120x120 mm, 6 Slots, Anodized Aluminium - Bosch Rexroth 3842994039
BOSCH REXROTH
Original product
Net price (excl. VAT)
€10.30
Item
BRR-3842994039
Manufacturer no.
3842994039
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.3842994039
Country of originGermany
Customs tariff number76169990
ConditionNew
Article
BRR-3842994039
Frequently Bought Together
-
This Item:
€10.30
-
Sealing Bar 10 for Profile Groove 45/30, L=3000 mm, Signal Grey RAL 7004 - Bosch Rexroth 3842555560
€20.49
-
SL12LED Basic System Lamp for Assembly Profiles - Bosch Rexroth 3842563246
€152.97
Total price
The 120x120 mm cable management profile integrates cable and hose routing directly into the profile interior - eliminating separate cable ducts in Rexroth assembly structures. The two-part system (profile and cover) is supplied in variable lengths between 100 mm and 6070 mm, with M12 tapping in all core holes for direct integration into the Bosch Rexroth aluminium profile system.
- Concealed 10 mm groove for mounting socket strips or installation elements - keeps wiring out of sight
- Cover with hinge function on both sides for quick access from either direction
- Mounts for dividing strips and grounding cables provide organised potential distribution
- Integrated mount for potential equalizer line (accessory 3842552234)
- Screw holes for cover plates; M12 threads in all core holes
- Closed exterior face - suitable for safety-critical and cleanliness-sensitive environments
Technical data
| Specification | Value |
|---|---|
| Cross-section | 120 x 120 mm |
| Open slots | 6 |
| Min. length (L min) | 100 mm |
| Max. length (L max) | 6070 mm |
| Delivery unit | 1 piece (variable length) |
| Thread adaptation | M12 in all core holes |
| Material | Aluminium, anodized |
| Condition on delivery | Variable length, open slots |
| Recommended accessories | Self-tapping screw 3842552267 (cover fixing), Potential equalizer line 3842552234 |
| Weight | approx. 0.1 kg (length-dependent) |
| Manufacturer Nr. | 3842994039 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| HS-Code | 76169990 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
