AM Assembly Line Control Cabinet NA I3 0.9x0.6 with UPS and i5 Controller, 208 V / 60 Hz - Bosch Rexroth 3842564861
Datasheet (PDF)
The product may differ from the illustration
Complete, pre-wired control cabinet for Bosch Rexroth AM assembly systems in North American installations (208 V AC, 60 Hz). Integrates an i5 controller, an uninterruptible power supply (UPS, 24 V DC / 10 A), and all required electrical components. Supports Stop Category 1 emergency stop per DIN EN 60204-1 and connects via PROFINET, Ethernet/IP, or EtherCAT.

AM Assembly Line Control Cabinet NA I3 0.9x0.6 with UPS and i5 Controller, 208 V / 60 Hz - Bosch Rexroth 3842564861

BOSCH REXROTH Original product
Net price (excl. VAT)
€28,140.18
Excl. 19% VAT , excl. Shipping Cost
Available Fast shipping
Item BRR-3842564861
Manufacturer no. 3842564861
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842564861
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842564861
Frequently Bought Together
Total price

The AM PL NA I3 0.9x0.6 control cabinet delivers a ready-to-connect electrical control centre for Bosch Rexroth ActiveMover and AM assembly line systems in North American facilities running 208 V AC at 60 Hz. The graphite grey (RAL 7024) sheet-steel enclosure arrives fully wired - only the connecting kit requires on-site assembly - and bundles every component needed to commission the system without additional cabinet build-out.

  • Stop Category 1 emergency stop circuit per DIN EN 60204-1 for safety-compliant shutdown
  • Integrated UPS: 24 V DC / 10 A output maintains operation during brief power interruptions
  • Open PLC interface: PROFINET, Ethernet/IP, EtherCAT, and compatible protocols
  • Built-in filter and fan for active cabinet climate control, no external cooling required
  • Connecting kit included: ferrites, network cable, cable protection hose, 24 V cable, grounding cable, network coupler, and fastening hardware

Technical data

ParameterValue
VersionNA (North America)
Input voltage AC208 V
Output voltage AC208 V
Line current rating55 A
Frequency60 Hz
UPS output voltage DC24 V
UPS output current10 A
Controlleri5 processor
PLC interfacePROFINET, Ethernet/IP, EtherCAT and others
Cabinet colourGraphite grey RAL 7024
Housing materialSheet steel, painted
Filter colourRAL 7035
Mass70 kg (system); 75 kg (total)
Scope of deliveryControl cabinet (no assembly required), connecting kit, circuit diagram, i5 controller, UPS, all electrical system components
Required accessoriesInterface module PROFINET / Ethernet/IP / EtherCAT; control cabinet connecting kit
Recommended accessoriesConnecting cable for line, PLC, and AMpro installations
More Information
Manufacturer Nr. 3842564861
Manufacturer Bosch Rexroth
Weight 0.100000
GPSR manufacturer information Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
