The SP2/C-100 conveyor section profile forms the load-bearing track of the TS 2plus transfer system for longitudinal transport with flat top chain. The extruded, anodized aluminum profile is supplied in the 6070 mm standard length and accepts the accessories via profile slot 10. Slide profile GP 2, guide profile FP 2 and blocking bolts are required accessories.

Conveyor Section Profile SP2/C-100, Anodized Aluminum, 6070 mm, Slot 10 - Bosch Rexroth 3842532609

Name: Conveyor Section Profile SP2/C-100, Anodized Aluminum, 6070 mm, Slot 10 - Bosch Rexroth 3842532609
Brand: Bosch Rexroth
SKU: BRR-3842532609
Price: 7431.61 EUR
Availability: InStock

BOSCH REXROTH Original product

Net price (excl. VAT)

€7,431.61

Excl. 19% VAT , excl. Shipping Cost

Available Fast shipping

Item BRR-3842532609

Manufacturer no. 3842532609

Personal expert advice

Brand new Specialist dealer since 2009 Original product Worldwide shipping

Product data

Manufacturer no.3842532609

Country of originGermany

Customs tariff number76042100

ConditionNew

Article

BRR-3842532609

Frequently Bought Together

This Item: Conveyor Section Profile SP2/C-100, Anodized Aluminum, 6070 mm, Slot 10 - Bosch Rexroth 3842532609
€7,431.61
Excl. 19% VAT , excl. Shipping Cost
Accumulation Roller Chain 1/2" x 5/16" ESD, PA 12 Support Wheels, 12 m - Bosch Rexroth 3842523918
€1,030.33
Excl. 19% VAT , excl. Shipping Cost
Transmission Drive CSS, ESD, 12 Nm - Bosch Rexroth 3842542550
€974.07
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

The SP2/C-100 conveyor section profile is the load-bearing base profile of the section units in the Bosch Rexroth TS 2plus transfer system and is used for longitudinal transport with flat top chain. It is intended for special and general machine builders setting up a stable, dimensionally accurate conveyor track.

Extruded anodized aluminum profile for high stiffness at low weight
6070 mm standard length for cutting to the required track dimension
Profile slot 10 to accept the slide profile, guide profile and blocking bolts

Technical data

Material	Aluminum, anodized
Length [L]	6070 mm
Profile slot	10
Profile surface [A]	15 cm²
Moment of resistance in x-direction [Wx]	24.6 cm³
Area moment of inertia in x-direction [Ix]	128 cm⁴
Moment of resistance in y-direction [Wy]	16.4 cm³
Area moment of inertia in y-direction [Iy]	37 cm⁴
Mass [m]	4 kg/m
Delivery unit	16
Required accessories	Slide profile GP 2, guide profile FP 2, blocking bolts
Weight (delivery unit)	413 kg

Information

More Information
Execution	TEC
Manufacturer Nr.	3842532609
Manufacturer	Bosch Rexroth
Country of Manufacture	Germany
Weight	0.100000
HS-Code	76042100
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticity	Original product
Condition of article	New
