The ST 2/C-H conveyor section profile forms the load-bearing conveyor track for longitudinal transport with flat top chain in the Bosch Rexroth TS 2plus transfer system. Made of anodized aluminum with profile slot 10, it holds the matching glide and guide profiles. Supplied as a packaging unit of 12 profiles in the 6070 mm standard length.
Conveyor Section Profile ST 2/C-H, Anodized Aluminum, Slot 10, 6070 mm - Bosch Rexroth 3842536793
BOSCH REXROTH
Original product
Net price (excl. VAT)
€5,812.21
Item
BRR-3842536793
Manufacturer no.
3842536793
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.3842536793
Country of originGermany
Customs tariff number76042100
ConditionNew
Article
BRR-3842536793
Frequently Bought Together
-
This Item:
€5,812.21
-
Attachment kit for TS 2plus transfer system - Bosch Rexroth 3842518828
€86.87
-
Master Link Flat Top ESD Chain, Nickel-Plated, with Flat Top Plate - Bosch Rexroth 3842551234
€8.75
Total price
The ST 2/C-H conveyor section profile is a load-bearing aluminum profile for longitudinal transport with flat top chain in the Bosch Rexroth TS 2plus transfer system. It holds the glide and guide profiles and forms the conveyor track of the section unit.
- Anodized aluminum for high rigidity at low weight
- Profile slot 10 for mounting glide and guide profiles as well as accessories
- Standard length 6070 mm, supplied as a packaging unit of 12 profiles
Technical data
| Attribute | Value |
|---|---|
| Material | Aluminum, anodized |
| Profile slot | 10 |
| Length [L] | 6070 mm |
| Mass [m] | 5.3 kg/m |
| Profile surface [A] | 19.3 cm² |
| Area moment of inertia Ix | 156.8 cm⁴ |
| Area moment of inertia Iy | 54.9 cm⁴ |
| Moment of resistance Wx | 31.9 cm³ |
| Moment of resistance Wy | 21.4 cm³ |
| Condition on delivery | Packaging unit in standard length |
| Packaging unit | 12 profiles |
| Weight (packaging unit) | 390 kg |
| Required accessories | FP 2/H-St guide profile, GP 2/H-St glide profile, GP 2/H-Kst glide profile, ST 2/C-H adapter plate kit, cover rail for cable duct, blocking bolts |
| ESD version | TEC |
|---|---|
| Manufacturer Nr. | 3842536793 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| HS-Code | 76042100 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
