Bosch Rexroth 3842993743. Strut profile 45x60 Q&E

Condition on delivery

Profile finishing

Modular dimension [mm]

45

Cross-section

45x60

Profile slot

10

Open slots

4

Dimensions

45x60

Profile type

Standard

Color

Natural

Length min [L min] [mm]

50

Packaging unit

1

Length max [L max] [mm]

6070

Mass [m]

3

Notice

DGmax = 30, Lmin1 / Lmin2 = 404/508mm,Standard profile finishing at specified slots

Profile surface [A] [cm]

11

Moment of resistance in the y-direction [Wy] [cm]

10.1

Area moment of inertia in y-direction [ly] [cm]

22.7

Torsional moment of inertia [It] [cm]

6.7

Moment of resistance in the x-direction [Wx] [cm]

12.4

Area moment of inertia in x-direction [lx] [cm]

37.2

Moment of torsion resistance [Wt] [cm]

4.09

Standard profile finishing

M12 / M16 / D9,8 / D17 / DB17 / F1A,C

Customized profile finishing

DI / DIS / MT / MTS / MI / MIS / DG

Standard profile finishing minimum length

Observe minimum length

Standard profile finishing [L max] [mm]

6000

Individual profile finishing [L max i] [mm]

4900

Material

aluminum, anodized

Recommended accessories

Cover cap 45x60, black,Cover cap 45x60, signal gray,Cover cap with hole 45x60, black,Cover cap with hole 45x60, signal gray

Weight [kg]

0
