The product may differ from the illustration
Festo pneumatic component for industrial automation and compressed-air applications in proven quality.
Plug NECU-S-M12G3-HX-Q7 - Festo 564946
FESTO Original product
Net price (excl. VAT)
€14.74
Item FES-564946
Manufacturer no. NECU-S-M12G3-HX-Q7
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.NECU-S-M12G3-HX-Q7
EAN4052568056995
Customs tariff number85366990
ConditionNew
Article
FES-564946
Frequently Bought Together
- This Item: €14.74
- Distributor NEDY-L2R1-V1-C1W4L-U-0.3L-M8G# - Festo 8035785 €35.26
- Plug Socket MSSD-EB - Festo 151687 €2.37
Total price
Festo pneumatic component for industrial automation and compressed-air applications in proven quality. The key technical data of this genuine Festo article are listed below.
| Based on standard | EN 61076-2-101<br>EN 61984 |
| Operating voltage range DC [V] | 0 to 48 |
| Operating voltage range AC [V] | 0 to 48 |
| Current carrying capacity at 40°C [A] | 6,0 |
| Surge voltage strength [kV] | 0,8 |
| Permitted cable diameter [mm] | 4.7 to 6 |
| Connection cross-section [mm²] | 0.34 to 0.75 |
| Protection category | IP65<br>IP67 |
| ambient temperature [°C] | -25 to 85 |
| Material information | Copper and PTFE-free<br>RoHs compliant |
| Degree of contamination | 3 |
| Corrosion resistant class KBK | 1 - low corrosion stress |
| Housing material | PA<br>nickel-plated<br>Zinc pressure cast |
| Plug contacts material | Gold plated |
| Connection frequency | 3 |
| Product weight [g] | 32,8 |
| Screw lock material | Zinc pressure cast, nickel-plated |
| Seals material | FKM<br>PUR |
| Permission | c UL us - Recognized (OL) |
| Electrical connection | M12x1<br>3 pin<br>Plug straight / Crimp terminal<br>A-coded |
| Permitted individual wire diameter [mm] | >= 0.1 mm |
| Permitted wire diameter [mm] | 1.6 to 2 |
| Permitted wire insulation | PVC |
| Manufacturer Nr. | NECU-S-M12G3-HX-Q7 |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568056995 |
| Weight | 0.033000 |
| HS-Code | 85366990 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Werkstoff | Zink-Druckguss |
| Schutzart | IP65 |
