The product may differ from the illustration
Festo fitting or line component for fast, leak-tight and pressure-resistant compressed-air connections.
Sub-Base VMPAL-AP-10-T135 - Festo 554315
FESTO Original product
Net price (excl. VAT)
€6.83
Item FES-554315
Manufacturer no. VMPAL-AP-10-T135
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.VMPAL-AP-10-T135
EAN4052568053659
Customs tariff number84819000
ConditionNew
Article
FES-554315
Frequently Bought Together
- This Item: €6.83
- Sub-Base VMPAL-AP-14 - Festo 560973 €7.50
- Sub-Base VMPA2-FB-AP-2-1-T0-RV - Festo 8034550 €48.73
Total price
Festo fitting or line component for fast, leak-tight and pressure-resistant compressed-air connections. The key technical data of this genuine Festo article are listed below.
| Width [mm] | 10,7 |
| Length [mm] | 107,3 |
| Pitch dimension [mm] | 10,7 |
| Valve size [mm] | 10 |
| Max. number of valve spaces | 1 |
| Flow direction | Reversible |
| Valve island structure | Valve sizes mixable |
| Operating pressure [bar] | -0.9 to 10 |
| Control pressure [bar] | 3 to 8 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 3 - severe corrosion stress |
| ambient temperature [°C] | -5 to 50 |
| Product weight [g] | 25,00 |
| Pneumatic connection 2 | for cartridge 10 mm |
| Pneumatic connection 4 | for cartridge 10 mm |
| Material information | RoHs compliant |
| Connection plate material | PA reinforced |
| Pressure zone separation | Channel 1, 3 and 5 |
| Manufacturer Nr. | VMPAL-AP-10-T135 |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568053659 |
| Weight | 0.048000 |
| HS-Code | 84819000 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Betriebsdruck max [bar] | 10.000000 |
