EPA Kombi-Gate entrance system with turnstile, barrier and EPA-RESIST 6.000 - A1-ESD EP0301068

The EPA Kombi-Gate controls access to an EPA zone at a single point for two types of traffic: people pass through a turnstile, while materials and transport trolleys pass through a side swing barrier. This keeps personnel flow separate from goods logistics without building a second airlock.

Benefits

• Personnel pass only after a successful grounding measurement on the integrated EPA-RESIST 6.000
• Separate goods and trolley passage through the swing barrier, bypassing the turnstile
• LED status ring signals free or blocked and shows the system state from a distance
• Chrome-plated swivel and barrier arms with printed warning markings

Technical data

• System type: combined turnstile and swing barrier
• Personnel tester: EPA-RESIST 6.000, tests wrist strap and footwear
• Tester measuring voltage: 33 V, 50 V or 100 V selectable
• Operating side: left- or right-hand operation
• Status indication: LED ring

Applications

Main entrances to EPA areas in electronics manufacturing, cleanroom ante-areas and warehouse interfaces where personnel and trolleys use the same entrance.

Standards and compliance

Supports the setup and operation of an EPA according to IEC 61340-5-1. Personnel grounding tests document compliance with the limit values for wrist straps and footwear.
