Curve module for 180° direction changes in AM transfer systems, operating at 28 V DC. The set includes guide rail (L = 500 mm), cable set, and all fixing hardware for rapid commissioning. An integrated encoder provides contactless workpiece pallet position detection.
Curve Module AM 28 V DC 180° Set - Bosch Rexroth 3842559430
BOSCH REXROTH Original product
Net price (excl. VAT)
€26,303.77
Item BRR-3842559430
Manufacturer no. 3842559430
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842559430
ConditionNew
Article
BRR-3842559430
Frequently Bought Together
- This Item: €26,303.77
- Belt Section BS 2/C-250 - Bosch Rexroth 3842998934 €3,601.61
- Cover Rail 120 ESD for Cable Guide Profiles 60x120 / 120x120, PP - Bosch Rexroth 3842558512 €18.00
Total price
The 3842559430 curve module handles 180° direction changes in AM transfer systems and runs at 28 V DC. An integrated measuring system (encoder) detects the workpiece pallet position contactlessly. Because the guide rollers on the workpiece pallet are not interlocked with the system, pallets can be removed quickly and without tools. A removable cover protects the electronics.
- Integrated encoder for contactless workpiece pallet position detection
- Fast, easy pallet removal - guide rollers not interlocked with the system
- Complete set: connection kit, guide rail L = 500 mm, adjustment wedge, connection block, cable set (0 V, 24 V, 28 V DC, grounding cable, network cable) and installation material
- Fixing plate for mounting to base frame included
- Sturdy build: anodized aluminum, stainless steel, PA, PC and epoxy
Technical data
| Specification | Value |
|---|---|
| Motor voltage DC | 28 V |
| Control voltage DC | 24 V |
| Output power | 10 W |
| Mass | 65 kg |
| Shipping weight | 0.1 kg |
| Curve angle | 180° |
| Materials | Aluminum anodized, stainless steel, PA, PC, epoxy |
| Fastening material | Included |
| Delivery condition | Partially assembled |
| Manufacturer Nr. | 3842559430 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
