Glamox C52124105. Interior General Lighting C52-S1500 24000 WR CHW-SEN 840 TW MB

Glamox
Lead time
4 weeks
€769.30
Excl. 19% VAT , excl. Shipping Cost
Article
GL-C52124105

Manufacturer Nr.
C52124105
C52-S1500 24000 WR CHW-SEN 840 TW MB
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price

  • General

    1. Product shape
      Rectangular

  • Certificates

    1. Certification
      Ball test,5 year warranty

  • LMS System

    1. LMS Wireless solution
      868 MHz
    2. Number of DALI addresses
      2

  • Electrical Data

    1. Leakage current (mA)
      0.50
    2. Voltage from (V)
      220
    3. Maximum voltage (V)
      240
    4. Minimum frequency (Hz)
      50
    5. Maximum frequency (Hz)
      60
    6. Total consumption (W)
      153
    7. IEC Protection Class
      I
    8. Number of luminaires on a 10A MCB type B (80% load)
      7
    9. Number of luminaires on a 10A MCB type C (80% load)
      10
    10. Number of luminaires on a 16A MCB type B (80% load)
      12
    11. Number of luminaires on a 16A MCB type C (80% load)
      20

  • Technical Data

    1. Minimum ambient temperature (ºC)
      0
    2. Maximum ambient temperature (°C)
      25
    3. IK classification
      06
    4. IP classification
      20

  • Light Technical Data

    1. Light source
      LED
    2. Lumen out (lm)
      24,318
    3. Number of lamps
      1
    4. Lumen per Watt (lm/W)
      160
    5. Lamp colour temp (K)
      4000
    6. CRI Colour rendering index
      80
    7. MacAdam step
      3
    8. Energy class light source
      D
    9. Light source included
      Yes

  • Driver / Ballast

    1. Type of LED Driver
      WR: Wireless Radio
    2. Number of Driver
      2

  • Lifetime

    1. L70 Median useful life LED Ta25 (hr)
      100 000
    2. L80 Median useful life LED Ta25 (hr)
      100 000
    3. L90 Median useful life LED Ta25 (hr)
      50 000
    4. L70 Median useful life LED MaxTa (hr)
      100 000
    5. L80 Median useful life LED MaxTa (hr)
      100 000
    6. Median useful life driver Ta25 (hr)
      100,000

  • Sensor

    1. Sensor type
      PIR
    2. Detection angle crosswise (°)
      92
    3. Detection angle lengthwise (°)
      102
    4. Max mounting height / detection range (metre)
      10
    5. Sensor max hold time
      Programmable
    6. Sensor min hold time
      Programmable

  • Optic

    1. Optic
      MB - Medium beam

  • Housing

    1. Main body material
      Aluminium
    2. Body colour
      White
    3. Main body colour name
      Traffic white
    4. Main body colour RAL code
      RAL 9016
    5. End cap material
      Aluminium
    6. End Cap colour
      White

  • Dimensions

    1. Length (mm)
      1,464
    2. Width (mm)
      216
    3. Height (mm)
      43
    4. CC max
      1,347
    5. Net weight (kg)
      7.69

  • Termination

    1. Termination
      5x2x2.5mm2 Push In
    2. Type of through wiring
      5x2.5

  • Cable Inlet

    1. Cable gland
      Grommet
    2. Number of cable entries
      8
    3. Max cable diameter (mm)
      16

  • Mounting

    1. Product mounting
      Ceiling Surface

  • Logistic Data

    1. Item gross weight (kg)
      8.36
More Information
Manufacturer Nr. C52124105
Manufacturer Glamox
EAN 5903531241056
Lead time 4 weeks
Weight 8.360000
Colour 4000K
Lenght 1464
GPSR manufacturer information Glamox GmbH Daimlerring 25 DE-31135 Hildesheim www.glamox.com
Article authenticity Original product
Condition of article New
