Solder fume extraction V 1500 iQ central unit for up to 20 users 230 V - Donaldson Bofa 15811592-1419

Where several soldering benches or an automatic soldering line have to be extracted, the available pressure reserve decides how well each individual point captures. The Donaldson Bofa V 1500 iQ combines a very large filter capacity with high airflow and high pressure and works as a centralized system for up to 20 users on 32 mm arms. The iQ operating system keeps performance, safety, maintenance effort and running costs under control.

Benefits

• Central unit for up to 20 users with 32 mm extraction arms
• iQ operating system with automatic flow control and real-time airflow display
• Reverse-flow air filtration and DeepPleat DUO pre-filter for long service life
• Independent filter condition monitoring with display and warnings
• High contrast display and remote diagnostics via USB
• Powder-coated housing for continuous production use

Technical data

Applications

Central solder fume extraction in electronics manufacturing, extraction at automatic soldering and wave soldering machines, and demanding applications that need high volume flow across several capture points.

Compatibility and scope of delivery

Designed for Bofa extraction arms of 32 mm diameter and for the pre-filter and main filter elements of the V 1500 iQ series. Supplied as the V 1500 iQ extraction unit in 230 V version with the iQ operating system and filters fitted. Extraction arms, hose sets and replacement filters are available separately.
