Bofa Solder Fume Extraction
Fume Extractions
Donaldson Bofa extraction systems cover the stationary and industrial solder fume extraction segment. The core product is the WLA 250 extraction system with an extensive ESD-safe accessories programme: extraction arms with funnel or nozzle in D 32 and D 50 mm, LED funnel, flat hood and flat nozzle for various positioning requirements. All Bofa extraction arms with ESD marking (1UA1020...) are suitable for use in EPA zones.
| Item | Diameter | Variant |
|---|---|---|
| 1UA1020044 | D 32 mm | ESD extraction arm with funnel |
| 1UA1020046 | D 32 mm | ESD extraction arm with nozzle |
| 1UA1020045 | D 50 mm | ESD extraction arm with funnel |
| 1UA1020047 | D 50 mm | ESD extraction arm with nozzle |
| 1UA1020049 | D 50 mm | ESD extraction arm with flat nozzle |
| 1UA1020179 | D 50 mm | ESD extraction arm with flat hood |
| 1UA1020048 | D 50 mm | ESD extraction arm with nozzle, 1 m extended |
| 1UA1020169 | D 50 mm | ESD extraction arm with LED funnel, black |
Typical applications: Industrial fume extraction at multi-station soldering lines with WLA 250, ESD-safe extraction in EPA-certified production areas, assembly and rework with integrated LED lighting on the extraction arm (1UA1020169), retrofitting existing Bofa systems with the extended nozzle for hard-to-reach solder joints, and compliance with workplace threshold limits for flux vapours.
