Solder fume extraction unit V1000 iQ 850 m³/h for up to 15 workstations, 230 V - Donaldson Bofa 30811590-1419

Once more than a handful of soldering positions need extraction, one central unit is more economical than many bench units. The V1000 iQ delivers 850 m³/h at 100 mbar from a 2.2 kW drive, holds the set airflow through automatic flow control as the filters load, and reports the condition of each filter stage independently.

Benefits

• 850 m³/h at 100 mbar, serving up to 15 users from a single unit depending on the installation
• Automatic flow control system keeps extraction performance constant as filters load
• Combined HEPA and gas filter with ACF technology for particles and organic vapours
• DeepPleat DUO pre-filter with high dust holding capacity extends main stage life
• iQ operating system with high contrast display, independent filter monitoring and warning
• Run-safe operation and remote diagnosis via USB, CE certified

Technical data

Applications

Designed for heavy duty applications with a high particulate and gas load: central solder fume extraction for several manual workstations, extraction on selective and wave soldering machines, reflow processes as well as bonding, potting and coating benches with a solvent content. USB remote diagnosis makes operating and filter data available for maintenance planning.

Compatibility and scope of delivery

Supplied as the V1000 iQ extraction unit in the 230 V version with iQ control and installed filter cascade. Extraction arms, hose sets, nozzles and replacement filters are ordered separately and depend on the number of workstations to be connected.
