Festo AEVC-63-25-I-P-A (188277) Short-Stroke Cylinder
€14,503.00
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-188277
Manufacturer Nr.
AEVC-63-25-I-P-A
Short-Stroke Cylinder
Frequently Bought Together
-
This Item:
€14,503.00Excl. 19% VAT , excl. Shipping Cost
-
Festo ADVC-80-15-A-P (188321) Short-Stroke Cylinder
€17,061.00Excl. 19% VAT , excl. Shipping Cost
-
Festo AEVC-4-2,5-P (188050) Short-Stroke Cylinder
€3,427.00Excl. 19% VAT , excl. Shipping Cost
Total price
| Stroke [mm] | 25,0 |
| Piston diameter | 63 mm |
| Spring return force for retracted piston rod [N] | 50 |
| Dampening | P: Elastic silencer rings / plates double-sided |
| installation position | arbitrary |
| Principle of operation | Pressing single action |
| Construction set up | Piston piston rod |
| Position detection | For proximity switch |
| Operating pressure [bar] | 1 to 10 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 1 - low corrosion stress |
| ambient temperature [°C] | -20 to 80 |
| Theoretical force at 6 bar, flow [N] | 1.798,0 |
| Moving mass [g] | 179,00 |
| Product weight [g] | 870,0 |
| Fastening type | With throughway bores With Accessories Selectively: |
| Pneumatic connection | G1/8 |
| Material information | Copper and PTFE-free |
| Cover material | Aluminium wrought alloy anodized |
| Seals material | TPE-U(PU) |
| Housing material | Aluminium wrought alloy anodized |
| Piston rod material | High-alloyed steel |
| Based on standard | ISO 6431 VDMA 24562 hole pattern |
| Manufacturer Nr. | AEVC-63-25-I-P-A |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568148829 |
| Weight | 0.750000 |
| HS-Code | 84123100 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
