Airtec NADA 80/150. ISO 21287 cylinders, double acting, piston 80 mm, stroke 150 mm

Airtec
€16,601.00
Excl. 19% VAT , excl. Shipping Cost
Article
FL-NADA-80/150

Manufacturer Nr.
NADA 80/150
ISO 21287 cylinders, double acting, piston 80 mm, stroke 150 mm
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price
Materials:
Head and foot: Aluminium, cylinder tube: Anodized aluminium, piston rod: stainless steel, seal: NBR/PUR

Temperature range:
-20 to +80 °C

Operating pressure:
max. 10 bar

Version:
With Magnetic piston

Cylinder switch type:
D, A

Optional:
Piston rod with male thread -male thread

Piston diameter [mm] 80
Stroke [mm] 150
Version non-rotating piston rod
G (compressed air port) G 1/8"
Repair sets NAD 80 REP
A [mm] 20
B [mm] 12
BG [mm] 15,0
CH [mm] 17
D [mm] 28
D1 [mm] 65
D2 M 8
D3 [mm] 8
E [mm] 95,5
LA [mm] 3,0
RT M 10
TG [mm] 72,0
WH [mm] 10
ZA [mm] 54
ZC [mm] 38
ZD [mm] 78
More Information
Manufacturer Nr. NADA 80/150
Manufacturer Airtec
EAN 4050571520328
Weight 31.000000
HS-Code 84123100
GPSR manufacturer information AIRTEC Pneumatic GmbH, Westerbachstraße 7, DE-61476 Kronberg, www.airtec.de
Article authenticity Original product
Condition of article New
