Airtec NXDA 100/15. Compact cylinders, double acting, piston 100 mm, stroke 15 mm

Name: Airtec NXDA 100/15. Compact cylinders, double acting, piston 100 mm, stroke 15 mm
Brand: Airtec
SKU: FL-NXDA-100/15
Price: 26397 EUR
Availability: InStock

€26,397.00

Excl. 19% VAT , excl. Shipping Cost

Article

FL-NXDA-100/15

Manufacturer Nr.

NXDA 100/15

Compact cylinders, double acting, piston 100 mm, stroke 15 mm

Skip to the end of the images gallery

Skip to the beginning of the images gallery

The product may differ from the illustration

Frequently Bought Together

This Item: Airtec NXDA 100/15. Compact cylinders, double acting, piston 100 mm, stroke 15 mm
€26,397.00
Excl. 19% VAT , excl. Shipping Cost
Airtec NXDA 50/200. Compact cylinders, double acting, piston 50 mm, stroke 200 mm
€20,821.00
Excl. 19% VAT , excl. Shipping Cost
Airtec NXD 80/130-AG. Compact cylinders, double acting, piston 80 mm, stroke 130 mm
€21,354.00
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

Materials:
Head and base: Anodized aluminium, cylinder tube: Anodized aluminium, piston rod: 1.4305, seal: PUR

Temperature range:
-20 to +80 °C

Operating pressure:
max. 10 bar

Version:
With Magnetic piston

Cylinder switch type:
D, A

Optional:
Piston rod with male thread -male thread

Piston diameter [mm]	100
Stroke [mm]	15
Version	non-rotating piston rod
M (compressed air port)	G 1/4"
Repair sets	NXD 100 REP
A [mm]	124
B [mm]	25
C [mm]	8
D [mm]	8,5
E	M 10
F [mm]	13,5
G [mm]	30
H [mm]	14
I	M 10
J [mm]	66,5
K [mm]	10
L [mm]	0
N [mm]	10,5
O [mm]	19,25
P [mm]	103
R [mm]	80
S [mm]	56,6
T [mm]	22
U [mm]	8,5
W [mm]	10,0
X [mm]	3,0
Y [mm]	14
Z [mm]	10,0

Information

More Information
Manufacturer Nr.	NXDA 100/15
Manufacturer	Airtec
EAN	4050571529871
Weight	31.000000
HS-Code	84799070
GPSR manufacturer information	AIRTEC Pneumatic GmbH, Westerbachstraße 7, DE-61476 Kronberg, www.airtec.de
Article authenticity	Original product
Condition of article	New
