High-Power Soldering Iron 140W 24V - Hakko FM-2030

Overview

The Hakko FM-2030 is a high-powered 140W soldering iron engineered for demanding applications requiring exceptional heat capacity. This composite-type iron features a built-in heater and is specifically designed for soldering large-scale components such as power supply boards, heat sinks, shield cases, and coaxial cables. Despite its high power output, the FM-2030 maintains a thin, ergonomic grip comparable to the FM-2027 model, with integrated thermal protection to shield users from radiant heat.

Key Features

• 140W high heat capacity for rapid thermal transfer to large components
• Composite construction with integrated heating element
• Thin, ergonomic grip with dual thermal protection design
• Compatible with 16 different T22 series soldering tips
• Suitable for both large-scale and micro-component applications on multilayer boards
• Significantly reduces production time compared to standard irons
• 24V operation for safe, controlled power delivery

Technical Specifications

Applications

The FM-2030 excels in industrial soldering environments where high thermal demand is critical. Ideal for power supply board assembly, heat sink attachment, shielded enclosure soldering, and coaxial cable termination. The versatile tip selection also enables precision work on multilayer PCBs with mixed component densities, making it suitable for both heavy-duty and fine-pitch applications.

Scope of Delivery

• FM-2030 soldering iron handpiece with integrated heater
• Connection cable for FM-203 or FM-206 station
• Instruction manual (available in multiple languages)
