Festo MHE2-MS1H-3/2O-QS-4 (196155) Solenoid Valve
€8,797.00
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-196155
Manufacturer Nr.
MHE2-MS1H-3/2O-QS-4
Solenoid Valve
Frequently Bought Together
-
This Item:
€8,797.00Excl. 19% VAT , excl. Shipping Cost
-
Festo MHP2-M1H-3/2O-M5 (196142) Solenoid Valve
€5,787.00Excl. 19% VAT , excl. Shipping Cost
-
Festo MHE2-M1H-3/2O-M7-K (196152) Solenoid Valve
€6,636.00Excl. 19% VAT , excl. Shipping Cost
Total price
| Valve function | 3/2 open monostable |
| Actuation type | Electrical |
| Build.width [mm] | 10 |
| Normal nominal flow [l/min] | 100 |
| Operating pressure [bar] | -0.9 to 8 |
| Construction set up | Pressure-relieved poppet valve |
| Reset mode | Mechanical spring |
| Protection category | IP65 |
| Permission | RCM mark c UL us - Recognized (OL) |
| Nominal width [mm] | 2 |
| Pitch dimension [mm] | 14 |
| Exhaust function | Can be throttled |
| Sealing principle | Soft |
| installation position | arbitrary |
| Hand assist actuation | tentative |
| Control type | Direct |
| Flow direction | Reversible with limitations |
| Überdeckung | negative Überdeckung |
| Operating pressure reversible [bar] | -0.9 to 1 |
| Max. switching frequency [Hz] | 330 |
| Shifting time off [ms] | 2,0 |
| Shifting time on [ms] | 1,7 |
| Power-on time | 100 % |
| Coil characteristic value | 24 V DC: Low current phase 1.25 W, high current phase 5 W |
| Permitted voltage oscillations | ± 10 % |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Oscillation strength | Transport use test with severity level 2 to FN 942017-4 and EN 60068-2-6 |
| Shock resistance | Shock test with degree of severity 2 to FN 942017-5 and EN 60068-2-27 |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Medium temperature [°C] | -5 to 60 |
| ambient temperature [°C] | -5 to 60 |
| Product weight [g] | 60 |
| Electrical connection | 2 pin Plug |
| Fastening type | With throughway bores |
| Pneumatic connection 2 | QS-4 |
| Material information | Copper and PTFE-free RoHs compliant |
| Seals material | HNBR NBR |
| Housing material | Coated Zinc pressure cast |
| Screws material | Steel zinc plating |
| KC-mark | KC-EMV |
| CE certificate (see declaration of conformity) | to EU EMC directive |
| Reverse polarity protection | Bipolar |
| Additional functions | Spark suppression Holding current reduction protection circuit |
| Tolerance shifting time off | +10 %/-30 % |
| Tolerance shifting time on | +10%/-30% |
| Shifting time scatter from 1 Hz [ms] | 0,2 |
| Limits ambient and media temperature | Depending on the switching frequency |
| Pneumatic connection 11 | QS-4 |
| Pneumatic connection 33 | QS-4 |
| Manufacturer Nr. | MHE2-MS1H-3/2O-QS-4 |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568159283 |
| Weight | 0.075000 |
| HS-Code | 84812090 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
