Name: Sub-Base VMPAL-AP-20-T135 - Festo 560980
Brand: Festo
SKU: FES-560980
Price: 8.21 EUR
Availability: InStock

This Item: Sub-Base VMPAL-AP-20-T135 - Festo 560980
€8.21
Excl. 19% VAT , excl. Shipping Cost
End Plate VMPAL-EPL-SD25 - Festo 560938
€20.65
Excl. 19% VAT , excl. Shipping Cost
Multi-Pin Plug CPV10-VI-P6-M7-D - Festo 538813
€126.68
Excl. 19% VAT , excl. Shipping Cost

Total price

Festo fitting or line component for fast, leak-tight and pressure-resistant compressed-air connections. The key technical data of this genuine Festo article are listed below.

Width [mm]	21,2
Length [mm]	107,3
Pitch dimension [mm]	21,2
Valve size [mm]	20
Max. number of valve spaces	1
Flow direction	Reversible
Valve island structure	Valve sizes mixable
Operating pressure [bar]	-0.9 to 10
Control pressure [bar]	3 to 8
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium	Oiled operation possible (required in further operations)
Corrosion resistant class KBK	3 - severe corrosion stress
ambient temperature [°C]	-5 to 50
Product weight [g]	46,70
Pneumatic connection 2	for cartridge 18 mm
Pneumatic connection 4	for cartridge 18 mm
Material information	RoHs compliant
Connection plate material	PA reinforced
Pressure zone separation	Channel 1, 3 and 5

More Information
Manufacturer Nr.	VMPAL-AP-20-T135
Manufacturer	Festo
EAN	4052568056100
Weight	0.047000
HS-Code	84819000
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity	Original product
Condition of article	New
Betriebsdruck max [bar]	10.000000
