Festo VMPAL-AP-20-T35-RV (8034563) Sub-Base
€197.00
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-8034563
Manufacturer Nr.
VMPAL-AP-20-T35-RV
Sub-Base
Frequently Bought Together
-
This Item:
€197.00Excl. 19% VAT , excl. Shipping Cost
-
Festo VMPA14-IC-AP-S-1 (8023667) Sub-Base
€7,187.00Excl. 19% VAT , excl. Shipping Cost
-
Festo VMPAL-EU (560955) Plate
€817.00Excl. 19% VAT , excl. Shipping Cost
Total price
| Width [mm] | 21,2 |
| Length [mm] | 107,3 |
| Pitch dimension [mm] | 21,2 |
| Max. number of valve spaces | 1 |
| Flow direction | Not reversible |
| Valve island structure | Valve sizes mixable |
| Operating pressure [bar] | 0 to 10 |
| Control pressure [bar] | 3 to 8 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 3 - severe corrosion stress |
| ambient temperature [°C] | -5 to 50 |
| Product weight [g] | 50,00 |
| Pneumatic connection 2 | for cartridge 18 mm |
| Pneumatic connection 4 | for cartridge 18 mm |
| Material information | RoHs compliant |
| Connection plate material | PA reinforced |
| Pressure zone separation | Channel 3 and 5 |
| Integrated function | check valves |
| Build.width [mm] | 20 |
| Vacuum capable | no |
| Manufacturer Nr. | VMPAL-AP-20-T35-RV |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568283681 |
| Weight | 0.100000 |
| HS-Code | 84819000 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
