HQ 4 Lift Transverse Unit - Bosch Rexroth 3842998035
Datasheet (PDF)
The product may differ from the illustration
The HQ 4 lift transverse unit transfers workpiece carriers laterally out of or into the main conveyor flow in Bosch Rexroth transfer systems without interrupting line throughput. Its compact design integrates into tight line sections with minimal effort. At under 10 g, the unit is lightweight and straightforward to install or reposition.

HQ 4 Lift Transverse Unit - Bosch Rexroth 3842998035

BOSCH REXROTH Original product
Net price (excl. VAT)
€5,389.62
Excl. 19% VAT , excl. Shipping Cost
Item BRR-3842998035
Manufacturer no. 3842998035
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842998035
Country of originGermany
Customs tariff number84313900
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842998035

The HQ 4 lift transverse unit is a diverting element for Bosch Rexroth transfer systems. It moves workpiece carriers sideways - out of the running line or back into it - at defined stations for processing, buffering or inspection, while the main transport flow continues uninterrupted.

  • Lateral diversion of workpiece carriers without stopping the main conveyor
  • Compact form factor for integration into space-restricted line segments
  • Low weight simplifies installation and realignment
  • Designed for use in Bosch Rexroth HQ 4 series transfer systems

Technical data

SpecificationValue
Article number3842998035
DescriptionHQ 4 lift transverse unit
Weight0.0099 kg
ManufacturerBosch Rexroth
More Information
ExecutionTEC
Manufacturer Nr.3842998035
ManufacturerBosch Rexroth
Country of ManufactureGermany
Weight0.009900
HS-Code84313900
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticityOriginal product
Condition of articleNew
Download
File Icon Bosch Rexroth. Katalog Mechanik-Grundelemente (de) (30.56 MB)
File Icon Bosch Rexroth. TSplus Modular Conveyors for Flexible Manufacturing (en) (12.02 MB)
File Icon Bosch Rexroth. Catalog Basic Mechanic Elements (en) (30.55 MB)
File Icon Bosch Rexroth. Aluminum Structural Framing System (en) (29.62 MB)
File Icon Bosch Rexroth. Transfersystem TS 5 (de) (40.69 MB)
File Icon Bosch Rexroth. Transfer system TS 5 (en) (43.75 MB)
File Icon Bosch Rexroth Éléments mécaniques de base (fr) (36.36 MB)
