Festo drive motor for precise, dynamic motion tasks in automation technology.
Servo Motor EMMS-AS-190-SK-HS-ARB - Festo 1584920
FESTO Original product
Net price (excl. VAT)
€5,091.48
Item FES-1584920
Manufacturer no. EMMS-AS-190-SK-HS-ARB
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.EMMS-AS-190-SK-HS-ARB
EAN4052568242510
Customs tariff number85015220
ConditionNew
Article
FES-1584920
Frequently Bought Together
- This Item: €5,091.48
- Servo Motor EMMT-AS-60-M-LS-RM - Festo 5242205 €749.43
- Servo Motor EMMT-AS-60-M-HS-RM - Festo 5242209 €749.43
Total price
Festo drive motor for precise, dynamic motion tasks in automation technology. The key technical data of this genuine Festo article are listed below.
| ambient temperature [°C] | -10 to 40 |
| Bearing temperature [°C] | -20 to 60 |
| Relative humidity | 0 - 90 % |
| Complies to standard | IEC 60034 |
| Insulation protection class | F |
| Measurement class according to DIN 60034-1 | S1 |
| Temperature monitoring | PTC resistance |
| Protection category | IP54 |
| Electrical connection technology | Plug |
| Material information | RoHs compliant |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Permission | RCM mark<br>c UL us - Recognized (OL) |
| CE certificate (see declaration of conformity) | to EU EMC directive<br>to EU low voltage directive |
| Nominal voltage DC [V] | 565 |
| Winding switching type | Star internal |
| Polpaarzahl | 6 |
| Standstill torque [Nm] | 26,20 |
| Nominal torque [Nm] | 17,47 |
| Peak torque [Nm] | 80,0 |
| Nominal rotational speed [1/min] | 3.000 |
| Max. speed [1/min] | 5.300 |
| Nominal performance motor [W] | 5.490 |
| Nominal current motor [A] | 14,43 |
| Peak current [A] | 77,2 |
| Motor constant [Nm/A] | 1,211 |
| Voltage constant phase-phase [mVmin] | 75,40 |
| Winding resistance phase-phase [Ohm] | 0,283 |
| Winding inductivity phase-phase [mH] | 3,07 |
| Total output moment of gyration [kg/cm²] | 55,700 |
| Product weight [g] | 22.200 |
| Permitted axial shaft loading [N] | 250 |
| Permitted radial shaft loading [N] | 940 |
| Rotor position transducer | Resolver |
| Rotor position transducer interface | SIN/COs analogue signals |
| Rotor position transducer measurement principle | Inductive |
| MTTF, part component | 114 years, rotor position sensor<br>4469 years, holding brake |
| MTTFd, part component | 228 years, rotor position sensor |
| Holding torque brake [Nm] | 30 |
| Operating voltage DC brakes [V] | 24 |
| Power consumption brake [W] | 17,0 |
| Mass inertia Brake [kg/cm²] | 3,600 |
| Switching play holding brake | 5 million empty actuation (without frictional work!) |
| Shaft design feather key | DIN 6885<br>A 10 x 8 x 40 |
| Nominal operating voltage DC [V] | 565 |
| Manufacturer Nr. | EMMS-AS-190-SK-HS-ARB |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568242510 |
| Weight | 22.200000 |
| HS-Code | 85015220 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Schutzart | IP54 |
