Airtec NAD 100/250-AG. ISO 21287 cylinders, double acting, piston 100 mm, stroke 250 mm

Airtec
€17,153.00
Excl. 19% VAT , excl. Shipping Cost
Article
FL-NAD-100/250-AG

Manufacturer Nr.
NAD 100/250-AG
ISO 21287 cylinders, double acting, piston 100 mm, stroke 250 mm
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price
Materials:
Head and foot: Aluminium, cylinder tube: Anodized aluminium, piston rod: stainless steel, seal: NBR/PUR

Temperature range:
-20 to +80 °C

Operating pressure:
max. 10 bar

Version:
With Magnetic piston

Cylinder switch type:
D, A

Optional:
Piston rod with male thread -male thread

Piston diameter [mm] 100
Stroke [mm] 250
Version Piston rod with male thread
KK (piston rod male thread) M 16x1,5
G (compressed air port) G 1/8"
Repair sets NAD 100 REP
A [mm] 25
AK [mm] 28
B [mm] 12
BG [mm] 19,5
CH [mm] 21
E [mm] 113,5
LA [mm] 3,0
RT M 10
TG [mm] 89,0
WH [mm] 10
ZA [mm] 67
ZB [mm] 77
ZC [mm] 46
More Information
Manufacturer Nr. NAD 100/250-AG
Manufacturer Airtec
EAN 4050571516758
Weight 1.000000
HS-Code 84123100
GPSR manufacturer information AIRTEC Pneumatic GmbH, Westerbachstraße 7, DE-61476 Kronberg, www.airtec.de
Article authenticity Original product
Condition of article New
