Airtec NAD 80/350-AG. ISO 21287 cylinders, double acting, piston 80 mm, stroke 350 mm

Airtec
€14,143.00
Excl. 19% VAT , excl. Shipping Cost
Article
FL-NAD-80/350-AG

Manufacturer Nr.
NAD 80/350-AG
ISO 21287 cylinders, double acting, piston 80 mm, stroke 350 mm
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price
Materials:
Head and foot: Aluminium, cylinder tube: Anodized aluminium, piston rod: stainless steel, seal: NBR/PUR

Temperature range:
-20 to +80 °C

Operating pressure:
max. 10 bar

Version:
With Magnetic piston

Cylinder switch type:
D, A

Optional:
Piston rod with male thread -male thread

Piston diameter [mm] 80
Stroke [mm] 350
Version Piston rod with male thread
KK (piston rod male thread) M 16x1,5
G (compressed air port) G 1/8"
Repair sets NAD 80 REP
A [mm] 20
AK [mm] 28
B [mm] 12
BG [mm] 15,0
CH [mm] 17
E [mm] 95,5
LA [mm] 3,0
RT M 10
TG [mm] 72,0
WH [mm] 10
ZA [mm] 54
ZB [mm] 64
ZC [mm] 38
More Information
Manufacturer Nr. NAD 80/350-AG
Manufacturer Airtec
EAN 4050571519063
Weight 41.000000
HS-Code 84123100
GPSR manufacturer information AIRTEC Pneumatic GmbH, Westerbachstraße 7, DE-61476 Kronberg, www.airtec.de
Article authenticity Original product
Condition of article New
