EMC SFSBS 63/20-B. ISO 21287 cylinders, single acting, piston 63 mm, stroke 20 mm
€5,184.00
Excl. 19% VAT ,
excl. Shipping Cost
Article
FL-SFSBS-63/20-B
Manufacturer Nr.
SFSBS 63/20-B
ISO 21287 cylinders, single acting, piston 63 mm, stroke 20 mm
Frequently Bought Together
-
This Item:
€5,184.00Excl. 19% VAT , excl. Shipping Cost
-
Airtec NAEE 50/10. ISO 21287 cylinders, single acting, piston 50 mm, stroke 10 mm
€12,767.00Excl. 19% VAT , excl. Shipping Cost
-
Airtec NAEE 80/10. ISO 21287 cylinders, single acting, piston 80 mm, stroke 10 mm
€23,663.00Excl. 19% VAT , excl. Shipping Cost
Total price
Materials:
Head and foot: aluminium, cylinder tube: anodized aluminium, piston rod: stainless steel (Ø 32 - 63: hard chromium-plated steel) seal: NBR / PUR
Temperature range:
-20 to +80 °C
Operating pressure:
max. 10 bar
Version:
With Magnetic piston
Cylinder switch type:
D, A
Optional:
Piston rod with male thread -B
Head and foot: aluminium, cylinder tube: anodized aluminium, piston rod: stainless steel (Ø 32 - 63: hard chromium-plated steel) seal: NBR / PUR
Temperature range:
-20 to +80 °C
Operating pressure:
max. 10 bar
Version:
With Magnetic piston
Cylinder switch type:
D, A
Optional:
Piston rod with male thread -B
| Piston diameter [mm] | 63 |
| Stroke [mm] | 20 |
| Version | Piston rod with male thread |
| KK (piston rod male thread) | M 12x1,25 |
| G (compressed air port) | G 1/8" |
| Repair sets | SFS 63 REP |
| A [mm] | 22 |
| AD [mm] | 20 |
| AF [mm] | 16 |
| BG [mm] | 20 |
| CH [mm] | 17 |
| E [mm] | 74,0 |
| E1 [mm] | 3,5 |
| LA [mm] | 5 |
| PL1 [mm] | 17,0 |
| PL2 [mm] | 11,5 |
| RT | M 8 |
| S [mm] | 5 |
| TG [mm] | 56,5 |
| WH [mm] | 8 |
| ZA [mm] | 49 |
| ZB [mm] | 57 |
| Manufacturer Nr. | SFSBS 63/20-B |
|---|---|
| Manufacturer | E.MC |
| EAN | 4050571929886 |
| Weight | 9.000000 |
| HS-Code | 84123100 |
| Article authenticity | Original product |
| Condition of article | New |
