Festo HGPP-32-A (525664) Parallel Gripper
€122,125.00
Excl. 19% VAT ,
excl. Shipping Cost
Article
FES-525664
Manufacturer Nr.
HGPP-32-A
Parallel Gripper
Frequently Bought Together
-
This Item:
€122,125.00Excl. 19% VAT , excl. Shipping Cost
-
Festo DHEB-8-E-D-S-P (1320776) Bellows Gripper
€13,712.00Excl. 19% VAT , excl. Shipping Cost
-
Festo HGRT-25-A (563908) Radial Gripper
€6,427.00Excl. 19% VAT , excl. Shipping Cost
Total price
| size | 32 |
| Stroke per gripper jaw [mm] | 12,5 |
| Max. exchange precision [mm] | 0,1 |
| Repeatability grippers [mm] | <= 0,02 mm |
| Quantity Gripper jaws | 2 |
| Principle of operation | double acting |
| Gripper function | Parallel |
| Construction set up | Toothed rack/pinion |
| Position detection | For Hall sensors For inductive sensors |
| Open total gripping force at 6 bar [N] | 830 |
| Close total gripping force at 6 bar [N] | 830 |
| Operating pressure [bar] | 2 to 8 |
| Max. working frequency gripper [Hz] | 4 |
| Min. opening time a 6 bar [ms] | 76 |
| Min. closing time at 6 bar [ms] | 110 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| ambient temperature [°C] | 5 to 60 |
| Open gripper jaws at gripping force of 6 bar [N] | 415 |
| Close gripper jaws at gripping force at 6 bar [N] | 415 |
| Max. force on gripper jaws Fz static [N] | 720 |
| Max. torque on gripper jaws Mx static [Nm] | 30,0 |
| Max. torque on gripper jaws My static [Nm] | 30,0 |
| Max. torque on gripper jaws Mz static [Nm] | 30,0 |
| Max. mass per external griper finger [g] | 300 |
| Product weight [g] | 1.408 |
| Fastening type | with female thread |
| Pneumatic connection | G1/8 |
| Material information | Copper and PTFE-free |
| Cover cap material | POM |
| Housing material | Aluminium wrought alloy Hard anodised |
| Gripper jaws material | Aluminium wrought alloy nickel-plated |
| Manufacturer Nr. | HGPP-32-A |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568161873 |
| Weight | 1.500000 |
| HS-Code | 84798997 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
