Festo gripper for secure handling and positioning of workpieces in automated processes.
Radial Gripper HGRT-40-A - Festo 563912
FESTO Original product
Net price (excl. VAT)
€927.91
Item FES-563912
Manufacturer no. HGRT-40-A
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.HGRT-40-A
EAN4052568211127
Customs tariff number84798997
ConditionNew
Article
FES-563912
Frequently Bought Together
- This Item: €927.91
- Bellows Gripper DHEB-27-E-U-S-P - Festo 1320826 €295.35
- Bellows Gripper DHEB-12-E-U-E-L - Festo 1320811 €230.68
Total price
Festo gripper for secure handling and positioning of workpieces in automated processes. The key technical data of this genuine Festo article are listed below.
| size | 40 |
| Max. exchange precision [mm] | <= 0,2 mm |
| Max. gripper jaw play ax, ay [deg] | <= 0,1 deg |
| Max. opening angle [deg] | 180 |
| Rotational symmetry [mm] | <= 0,2 mm |
| Repeatability grippers [mm] | <= 0,02 mm |
| Quantity Gripper jaws | 2 |
| installation position | arbitrary |
| Principle of operation | double acting |
| Gripper function | radial |
| Construction set up | Force controlled movement cycle |
| Position detection | For inductive sensors<br>For proximity switch |
| Operating pressure [bar] | 3 to 8 |
| Max. working frequency gripper [Hz] | <= 2 Hz |
| Min. opening time a 6 bar [ms] | 283 |
| Min. closing time at 6 bar [ms] | 320 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 1 - low corrosion stress |
| ambient temperature [°C] | 5 to 60 |
| Open total gripping force at 6 bar [Ncm] | 3.892 |
| Close total gripping force at 6 bar [Ncm] | 3.526 |
| Mass inertia [kg/cm²] | 13,870 |
| Max. force on gripper jaws Fz static [N] | 400 |
| Max. torque on gripper jaws My static [Nm] | 17,5 |
| Max. torque on gripper jaws Mz static [Nm] | 1,6 |
| Lubrication interval guide elements [Mio SP] | 10 |
| Product weight [g] | 1.580 |
| Fastening type | Female thread and centring sleeve |
| Pneumatic connection | G1/8 |
| Material information | Copper and PTFE-free<br>RoHs compliant |
| Housing material | aluminium<br>Smooth anodised |
| Gripper jaws material | hardened<br>Steel |
| Manufacturer Nr. | HGRT-40-A |
|---|---|
| Manufacturer | Festo |
| EAN | 4052568211127 |
| Weight | 1.700000 |
| HS-Code | 84798997 |
| GPSR manufacturer information | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Article authenticity | Original product |
| Condition of article | New |
| Temperature (max.) | 60 |
| Material | Aluminium |
| Betriebsdruck max [bar] | 8.000000 |
| Pneumatic connection | G1/8 |
| Series | HGRT |
| Medium | Compressed air |
| Funktion | double-acting |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| Mounting position | arbitrary |
| Design | Force controlled movement cycle |
| Position sensing | Yes |
