Base Frame Connecting Kit for Curve Module - Bosch Rexroth 3842559453
Datasheet (PDF)
The product may differ from the illustration
Connecting kit for joining two base frames in the Rexroth assembly line system, suitable between section modules and between a curve module and a section module. The nickel-plated steel set is supplied unassembled and includes all fastening material for 180-degree / 500 mm curve modules.

Base Frame Connecting Kit for Curve Module - Bosch Rexroth 3842559453

BOSCH REXROTH Original product
Net price (excl. VAT)
€896.02
Excl. 19% VAT , excl. Shipping Cost
Item BRR-3842559453
Manufacturer no. 3842559453
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842559453
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842559453
Frequently Bought Together
Total price

The 3842559453 connecting kit joins two base frames within the Rexroth assembly line system - both between two section modules and between a curve module and a section module. Supplied as a complete nickel-plated steel set, it includes all fastening material required for installation.

  • Secure, play-free connection of two base frames
  • Compatible with 180-degree / 500 mm curve module
  • Nickel-plated steel for lasting corrosion resistance
  • Complete set including fastening material - no additional parts required
  • Delivered unassembled for flexible on-site installation

Technical data

ParameterValue
Article number3842559453
Condition on deliveryNot assembled
Packaging unitSet
MaterialSteel, nickel-plated
Mass [m]17
Delivery weight20 kg
Scope of deliverySet consisting of base frame connection kit for curve module 180 degrees 500 mm incl. fastening material
Recommended accessoriesBase frame
More Information
Manufacturer Nr.3842559453
ManufacturerBosch Rexroth
Weight0.100000
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticityOriginal product
Condition of articleNew
Download
File Icon Bosch Rexroth. Katalog Mechanik-Grundelemente (de) (30.56 MB)
File Icon Bosch Rexroth. TSplus Modular Conveyors for Flexible Manufacturing (en) (12.02 MB)
File Icon Bosch Rexroth. Catalog Basic Mechanic Elements (en) (30.55 MB)
File Icon Bosch Rexroth. Aluminum Structural Framing System (en) (29.62 MB)
File Icon Bosch Rexroth. Transfersystem TS 5 (de) (40.69 MB)
File Icon Bosch Rexroth. Transfer system TS 5 (en) (43.75 MB)
File Icon Bosch Rexroth Éléments mécaniques de base (fr) (36.36 MB)
