Rotary Unit DE 2 BG 4 for Workpiece Carriers up to 208 kg - Bosch Rexroth 3842998874
Datasheet (PDF)
The product may differ from the illustration
The Rotary Unit DE 2 BG 4 is a ready-to-install module for horizontal rotation and transport of workpiece carriers in assembly line transfer systems. It handles branch-offs and crossings for heavy pallets up to 208 kg, available in track widths of 640, 800, and 1040 mm.

Rotary Unit DE 2 BG 4 for Workpiece Carriers up to 208 kg - Bosch Rexroth 3842998874

BOSCH REXROTH Original product
Net price (excl. VAT)
€18,186.40
Excl. 19% VAT , excl. Shipping Cost
Available Fast shipping
Item BRR-3842998874
Manufacturer no. 3842998874
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842998874
Country of originGermany
Customs tariff number84313900
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842998874

The Rotary Unit DE 2 BG 4 is a ready-to-install module for horizontal rotation and transport of workpiece carriers in Bosch Rexroth assembly technology transfer systems. It enables branch-offs and crossings even for heavy workpiece pallets up to 208 kg, available in three track widths.

  • Supplied ready-to-install with supports - minimises on-site assembly effort
  • Maximum workpiece pallet total weight: 208 kg
  • Three track widths: 640, 800, and 1040 mm
  • Pneumatic operation: 5-6 bar, straight pneumatic connection 6 mm
  • Rotation times: 90° in 4 s, 180° in 7 s, 270° in 10 s
  • Optional: assembled protective cover (outer diameter then 1516 mm instead of 1500 mm)

Technical data

ParameterValue
Assembly groupBG 4
Track width in transport direction [b]640 / 800 / 1040 mm
Length in transport direction [lT]640 / 800 / 1040 mm
Belt section length [L]1324 / 1231 / 1031 mm
Transportation height [H]585 ... 1400 mm
Outer diameter without protective cover [D1]1500 mm
Outer diameter with protective cover [D2]1516 mm
Max. workpiece pallet total weight [mG]208 kg
Rotation time 90°4 s
Rotation time 180°7 s
Rotation time 270°10 s
Required compressed air [pmin]5 bar
Required compressed air [pmax]6 bar
Pneumatic straight connection6 mm
Delivery informationReady-to-install incl. supports; optional: protective cover assembled
Weight (module)0.100 kg (shipping weight)
More Information
Manufacturer Nr. 3842998874
Manufacturer Bosch Rexroth
Country of Manufacture Germany
Weight 0.100000
HS-Code 84313900
GPSR manufacturer information Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticity Original product
Condition of article New
