Damper DA 2/100-E for Workpiece Pallet Outfeed, TS 2plus - Bosch Rexroth 3842548585
Datasheet (PDF)
The product may differ from the illustration
Pneumatic damper DA 2/100-E for the controlled outfeeding of WT 2 workpiece pallets in the TS 2plus transfer system. Hard-anodized aluminum housing with a hardened steel stop. Mounts on an HQ 2/U-H or HQ 2/C-H stop gate.

Damper DA 2/100-E for Workpiece Pallet Outfeed, TS 2plus - Bosch Rexroth 3842548585

BOSCH REXROTH Original product
Net price (excl. VAT)
€527.28
Excl. 19% VAT , excl. Shipping Cost
Item BRR-3842548585
Manufacturer no. 3842548585
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842548585
Customs tariff number84313900
ConditionNew
Add to Wish List Add to Compare
Article
BRR-3842548585
Frequently Bought Together
Total price

The Bosch Rexroth DA 2/100-E damper is used for the controlled outfeeding of WT 2, WT 2/F, WT 2/H or WT 2/F-H workpiece pallets in the TS 2plus transfer system. It mounts on an HQ 2/U-H or HQ 2/C-H stop gate and gently decelerates the pallet during transfer.

  • Suitable for workpiece pallet total weights up to 100 kg, depending on nominal speed
  • Rugged housing in hard-anodized aluminum with a hardened steel stop
  • Pneumatic connection via 6 mm straight push-in fitting
  • High-temperature damper available on request

Technical data

Mass [m]5 kg
Workpiece pallet total weight [mG]100 kg
Nominal speed6, 9, 12, 15, 18 m/min
Max. total weight per speed100 / 100 / 100 / 95 / 55 kg
Operating temperature0 ... +60 °C
Pneumatic straight connection Ø6 mm
HousingAluminum, hard anodized
StopSteel, hardened
Scope of deliveryincl. fastening material
Delivery informationnot assembled
Weight2.1 kg
More Information
ExecutionTEC
Manufacturer Nr.3842548585
ManufacturerBosch Rexroth
Weight2.100000
HS-Code84313900
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Article authenticityOriginal product
Condition of articleNew
