The BS 2/C-250 belt section is a ready-to-install conveyor unit with its own drive for transporting workpiece carriers longitudinally or transferring them laterally between parallel conveyor lines together with HQ 2 lift-and-transfer units. The flat-top plastic chain in version KA = A qualifies the unit for use in ESD-protected areas (EPA). Motor mounting is available on the right, left, or centre, with cable/connector or terminal-box connection.
Belt Section BS 2/C-250, max. 250 kg Accumulation Load, ESD-Suitable - Bosch Rexroth 3842999985
BOSCH REXROTH Original product
Net price (excl. VAT)
€3,601.61
Item BRR-3842999985
Manufacturer no. 3842999985
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.3842999985
Country of originGermany
Customs tariff number84313900
ConditionNew
Article
BRR-3842999985
Frequently Bought Together
- This Item: €3,601.61
- Connecting Kit UM 2/B for TS 2plus Transfer System - Bosch Rexroth 3842179574 €5.98
- Chain Breaker for Plastic Flat Top Chain - Bosch Rexroth 8981010510 €139.39
Total price
The BS 2/C-250 belt section is a fully assembled conveyor unit designed to transport workpiece carriers along a line or to transfer them laterally between parallel conveyor tracks in combination with two HQ 2 lift-and-transfer units. The naturally anodised aluminium track profile combined with polyamide guide and slide profiles delivers a low-maintenance structure for medium accumulation loads up to 250 kg. Chain version KA = A meets the requirements for use in electrostatic-protected areas (EPA) in accordance with IEC 61340-5-1.
- Accumulation load up to 250 kg - suited to medium-weight workpiece carriers in assembly automation
- ESD-compatible chain (KA = A) - safe operation in EPA environments
- Track widths from 160 to 1200 mm and lengths from 300 to 6000 mm - individually configurable
- Nominal speeds of 6, 9, 12, 15, or 18 m/min selectable; vN = 0 for supply without motor and gearbox
- Motor mounting right, left, or centre; connection via cable/connector (S) or terminal box (K)
- Reversing operation not permitted; use of automatic lubrication unit LU 2 strongly recommended
- Rexroth 4EE energy-efficiency classification
Technical data
| Parameter | Value |
|---|---|
| Article number | 3842999985 |
| Designation | Belt section BS 2/C-250 |
| Max. accumulation load | 250 kg |
| ESD suitability | Yes (chain version KA = A, suitable for EPA) |
| Max. operating temperature | +40 °C |
| Track width b | 160 / 240 / 320 / 400 / 480 / 640 / 800 / 1040 / 1200 mm |
| Length l | 300 to 6000 mm |
| Nominal speed vN | 0 / 6 / 9 / 12 / 15 / 18 m/min |
| Motor connection | Cable/connector (S) or terminal box (K) |
| Motor mounting position | Right (R), left (L), centre (M) |
| Chain version | Standard (KA = N) or EPA-suitable (KA = A) |
| Track profile material | Aluminium, natural anodised |
| Guide profile material | Polyamide |
| Slide profile material | Polyamide |
| Delivery condition | Assembled |
| Weight | approx. 0.01 kg (base article; configuration-dependent) |
| Execution | TEC |
|---|---|
| Manufacturer Nr. | 3842999985 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.009900 |
| HS-Code | 84313900 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
