Dino-Lite AM4112PT
Lead time
1 week
€303.03
Excl. 19% VAT ,
excl. Shipping Cost
Article
AM4112PT
Manufacturer Nr.
AM4112PT
Dino-Lite television model with improved color rendering. It features the possibility to turn the LED's on and off by using the sensor on the microscope. This model Dino-Lite AM4112PT is connected to the television (PAL) instead of USB. This can be a major advantage in situations where real time images are vital, such as working on PCB's or other miniature objects. It can also be directly connected to a beamer or digital blackboard without using a PC. » Also available: AM4112PZT with polarizer. All these models are also available in a robust metal housing
Frequently Bought Together
-
This Item:
€303.03Excl. 19% VAT , excl. Shipping Cost
-
Dino-Lite AM73515MZTL. EDGE Mikroskop USB 3.0 / Polarisation / AMR / FLC / LWD
€1,169.00Excl. 19% VAT , excl. Shipping Cost
-
Dino-Lite AM7915MZTL
€1,169.00Excl. 19% VAT , excl. Shipping Cost
Total price
Additional Info
| Dino-Lite range: | Dino-Lite High Speed |
|---|
Lighting
| Light/ LED type: | White |
|---|---|
| Number of LEDs: | 8 |
| LED on/off switchable: | Yes |
| Infrared filter: | IR cut-filter >650 nm |
| Diffuser available: | MSAA111A1 (optional accessory) |
| Emission filter: | No |
| Polarizer: | No |
Optics
| Magnification: | 10-70x, 200x |
|---|---|
| Macro zoom: | No |
| Working distance: | Standard |
| Lens type: | Glass with anti-reflection coating |
Sensor
| Sensor type: | CMOS |
|---|---|
| Resolution: | 628x586 pixels |
| Maximum frame rate: | 30 fps at 27 MHz |
Compatibility
| Interface: | TV (RCA) PAL |
|---|---|
| Operating system: | - |
| Included software: | - |
| Supported image formats (Windows): | - |
| Supported video formats (Windows): | - |
| Supported image formats (MacOS): | - |
| Supported video formats (MacOS): | - |
| Imaging standards: | - |
Housing
| Housing material: | Composite/ plastic housing |
|---|---|
| Magnification lock: | Yes |
| Dimensions: | 10.5cm (L) x 3.2cm (D) |
| Weight: | 95g |
| Cable length: | 1.8m |
Features
| Special feature: | No |
|---|---|
| Measurement: | No |
| Calibration: | No |
| Microtouch sensor: | Yes |
| ESD safe: | No |
Information
| Package contents: | Microscope, Carry pouch, Power adapter, User manual | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Warranty information: | 2 years European warranty | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Regulatory approval: | CE, FCC, ROHS | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Price range: | €200,00 - €350,00 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Working distance/ field of view/ depth of field: |
|
| Execution | TEC |
|---|---|
| Manufacturer Nr. | AM4112PT |
| Manufacturer | Dino-Lite |
| Country of Manufacture | Taiwan, Province of China |
| EAN | 4712805473786 |
| ESD equipment | USB Mikroskop |
| Lead time | 1 week |
| Weight | 0.095000 |
| HS-Code | 90119090 |
| Article authenticity | Original product |
| Condition of article | New |
