Festo ADVC-12-10-P (530569) Short-Stroke Cylinder

Name: Festo ADVC-12-10-P (530569) Short-Stroke Cylinder
Brand: Festo
SKU: FES-530569
Price: 3787 EUR
Availability: InStock

€3,787.00

Excl. 19% VAT , excl. Shipping Cost

Article

FES-530569

Manufacturer Nr.

ADVC-12-10-P

Short-Stroke Cylinder

The product may differ from the illustration

Frequently Bought Together

This Item: Festo ADVC-12-10-P (530569) Short-Stroke Cylinder
€3,787.00
Excl. 19% VAT , excl. Shipping Cost
Festo ADVC-80-20-A-P (188322) Short-Stroke Cylinder
€17,391.00
Excl. 19% VAT , excl. Shipping Cost
Festo AEVC-50-25-A-P-A (188257) Short-Stroke Cylinder
€11,672.00
Excl. 19% VAT , excl. Shipping Cost

Total price

Stroke [mm]	10,0
Piston diameter	12 mm
Dampening	P: Elastic silencer rings / plates double-sided
installation position	arbitrary
Principle of operation	double acting
Construction set up	Piston piston rod
Position detection	without
Operating pressure [bar]	1 to 10
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium	Oiled operation possible (required in further operations)
Corrosion resistant class KBK	1 - low corrosion stress
ambient temperature [°C]	-20 to 80
Theoretical force at 6 bar, flow [N]	68,0
Moving mass [g]	7,70
Product weight [g]	42,0
Fastening type	With throughway bores With Accessories Selectively:
Pneumatic connection	M5
Material information	Copper and PTFE-free
Cover material	Aluminium wrought alloy anodized
Seals material	NBR TPE-U(PU)
Housing material	Aluminium wrought alloy anodized
Piston rod material	High-alloyed steel
Theoretical force at 6 bar, Return flow [N]	51,0

More Information
Manufacturer Nr.	ADVC-12-10-P
Manufacturer	Festo
EAN	4052568085834
Weight	0.033000
HS-Code	84123100
GPSR manufacturer information	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Article authenticity	Original product
Condition of article	New
