M-210-VU-230V. 2/2-way vacuum valve (NC), G 1", -0,9 to 1bar, 230V AC

Materials:
Body: brass, internal parts: 1.4104, seal: NBR (G 1/4": FKM)

Temperature range:
-10 to +80 °C, environment: max. +35 °C

Media:
neutral, gaseous and liquid media, vacuum (max. -0.9 bar)

Installation position:
with upright magnets (G 1/4": any)

Control voltages:
24 V DC, 230 V AC

Voltage tolerance:
± 10 %

Protection class:
IP 65 (plug size 3, G 1": Screw terminals)

Pressure input:
P

Vacuum inlet:
A

Information:
These valves are always supplied with a solenoid coil and a connector plug.

Control voltage	230 V AC
function	normally closed (NC)
Thread	G 1"
Operating pressure [bar]	-0.9 to 1
DN [mm]	24
Suction performance [m³/h]	150
Suction performance [l/min]	2500
Kv value* [l/min]	141,7
L [mm]	90
Power consumption (AC) [VA]	52
Structural shape solenoid coil	E
Spare solenoid coil	MAG E 230V
