M-214-VU-230V. 2/2-way vacuum valve (NC), G 1/4", -0,9 to 5bar, 230V AC

Name: M-214-VU-230V. 2/2-way vacuum valve (NC), G 1/4", -0,9 to 5bar, 230V AC
Brand: Fluidics equipment
SKU: FL-M-214-VU-230V
Price: 11162 EUR
Availability: InStock

€11,162.00

Excl. 19% VAT , excl. Shipping Cost

Article

FL-M-214-VU-230V

Manufacturer Nr.

M 214 VU 230V

2/2-way vacuum valve (NC), G 1/4", -0,9 to 5bar, 230 V AC

Skip to the end of the images gallery

Skip to the beginning of the images gallery

The product may differ from the illustration

Frequently Bought Together

This Item: M-214-VU-230V. 2/2-way vacuum valve (NC), G 1/4", -0,9 to 5bar, 230V AC
€11,162.00
Excl. 19% VAT , excl. Shipping Cost
VSP 50 B1 SI. Bellows suction pad, 1,5-way, P-series, 52x12mm, Silicone (50A), transparent
€927.00
Excl. 19% VAT , excl. Shipping Cost
M-338-VU-H-230V. 3/2-way vacuum valve, G 3/8", -0,9 to 10bar, 230V AC
€96,884.00
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

Materials:
Body: brass, internal parts: 1.4104, seal: NBR (G 1/4": FKM)

Temperature range:
-10 to +80 °C, environment: max. +35 °C

Media:
neutral, gaseous and liquid media, vacuum (max. -0.9 bar)

Installation position:
with upright magnets (G 1/4": any)

Control voltages:
24 V DC, 230 V AC

Voltage tolerance:
± 10 %

Protection class:
IP 65 (plug size 3, G 1": Screw terminals)

Pressure input:
P

Vacuum inlet:
A

Information:
These valves are always supplied with a solenoid coil and a connector plug.

Control voltage	230 V AC
function	normally closed (NC)
Thread	G 1/4"
Operating pressure [bar]	-0,9 up to 5
DN [mm]	5
Suction performance [m³/h]	7
Suction performance [l/min]	117
Kv value* [l/min]	8,3
L [mm]	50
Power consumption (AC) [VA]	20
Structural shape solenoid coil	A
Spare solenoid coil	MAG A 230V

Information

More Information
Manufacturer Nr.	M 214 VU 230V
Manufacturer	Fluidics equipment
EAN	4050571474805
Weight	0.470000
HS-Code	84812090
Article authenticity	Original product
Condition of article	New
