M-238-VU-230V. 2/2-way vacuum valve (NC), G 3/8", -0,9 to 2bar, 230V AC

Name: M-238-VU-230V. 2/2-way vacuum valve (NC), G 3/8", -0,9 to 2bar, 230V AC
Brand: Fluidics equipment
SKU: FL-M-238-VU-230V
Price: 15194 EUR
Availability: InStock

€15,194.00

Excl. 19% VAT , excl. Shipping Cost

Article

FL-M-238-VU-230V

Manufacturer Nr.

M 238 VU 230V

2/2-way vacuum valve (NC), G 3/8", -0,9 to 2bar, 230 V AC

Skip to the end of the images gallery

Skip to the beginning of the images gallery

The product may differ from the illustration

Frequently Bought Together

This Item: M-238-VU-230V. 2/2-way vacuum valve (NC), G 3/8", -0,9 to 2bar, 230V AC
€15,194.00
Excl. 19% VAT , excl. Shipping Cost
R 10-2 VU. Vacuum regulator without external leakage G 1"
€94,929.00
Excl. 19% VAT , excl. Shipping Cost
R 10 VU B. Vacuum regulator with external leakage G 1"
€10,172.00
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

Materials:
Body: brass, internal parts: 1.4104, seal: NBR (G 1/4": FKM)

Temperature range:
-10 to +80 °C, environment: max. +35 °C

Media:
neutral, gaseous and liquid media, vacuum (max. -0.9 bar)

Installation position:
with upright magnets (G 1/4": any)

Control voltages:
24 V DC, 230 V AC

Voltage tolerance:
± 10 %

Protection class:
IP 65 (plug size 3, G 1": Screw terminals)

Pressure input:
P

Vacuum inlet:
A

Information:
These valves are always supplied with a solenoid coil and a connector plug.

Control voltage	230 V AC
function	normally closed (NC)
Thread	G 3/8"
Operating pressure [bar]	-0.9 to 2
DN [mm]	10
Suction performance [m³/h]	24
Suction performance [l/min]	400
Kv value* [l/min]	35
L [mm]	54
Power consumption (AC) [VA]	24
Structural shape solenoid coil	B
Spare solenoid coil	MAG B 230V

Information

More Information
Manufacturer Nr.	M 238 VU 230V
Manufacturer	Fluidics equipment
EAN	4050571477264
Weight	0.600000
HS-Code	84812090
Article authenticity	Original product
Condition of article	New
