M-312-VU-230V. 3/2-way vacuum valve, G 1/2", -0,9 to 6bar, 230V AC

Fluidics equipment
€18,663.00
Excl. 19% VAT , excl. Shipping Cost
Article
FL-M-312-VU-230V

Manufacturer Nr.
M 312 VU 230V
3/2-way vacuum valve, G 1/2", -0,9 to 6bar, 230 V AC
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price
Materials:
Body: brass, internal parts: 1.4104, seal: FKM

Temperature range:
-10 to +80 °C, environment: max. +35 °C

Media:
neutral, gaseous and liquid media, vacuum (max. -0.9 bar)

Installation position:
with upright magnets (type standard: any)

Control voltages:
24 V DC, 230 V AC

Voltage tolerance:
± 10 %

Protection class:
IP 65 (plug size 3)

Pressure input:
P (type Universal: possible at every connection)

Vacuum inlet:
P (type Universal: possible at every connection)

Note:
In a standard type, the breathing takes place via the anchor (M 5 female thread).

Information:
These valves are always supplied with a solenoid coil and a connector plug.

Version Standard
Control voltage 230 V AC
function normally closed (NC)
Thread (2x) G 1/2"
Operating pressure [bar] -0.9 to 6
DN [mm] 3
Suction performance [m³/h] 5
Suction performance [l/min] 83
Kv value* [l/min] 3,3
L [mm] 60
Power consumption (AC) [VA] 20
Structural shape solenoid coil A
Spare solenoid coil MAG A 230V
More Information
Manufacturer Nr. M 312 VU 230V
Manufacturer Fluidics equipment
EAN 4050571477912
Weight 0.600000
HS-Code 84812090
Article authenticity Original product
Condition of article New
