ND 80/60. Short-stroke cylinders, double acting, piston 80 mm, stroke 60 mm

FLUIDICS EQUIPMENT Original product
Net price (excl. VAT)
€176.34
Excl. 19% VAT , excl. Shipping Cost
Available Fast shipping
Item FL-ND-80/60
Manufacturer no. ND 80/60
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.ND 80/60
EAN4050571523657
Customs tariff number84799070
ConditionNew
Add to Wish List Add to Compare
Article
FL-ND-80/60
ND 80/60. Short-stroke cylinders, double acting, piston 80 mm, stroke 60 mm
The product may differ from the illustration
Short-stroke cylinders, double acting, piston 80 mm, stroke 60 mm
Frequently Bought Together
Total price
Materials:
Head and base plate: Anodised aluminium / brass, cylinder tube: Anodised aluminium, piston rod: 1.4305 seal: NBR

Temperature range:
-20 to +80 °C

Operating pressure:
max. 10 bar

Cylinder switch type:
G

Piston diameter [mm] 80
Stroke [mm] 60
Version without magnetic piston
C1 (piston rod thread) M 10
P (compressed air port) G 1/4"
Repair sets ND 80 REP
A [mm] 105,0
B [mm] 100
D [mm] 20
F [mm] 9,0
G [mm] 14,0
H [mm] 55,0
I [mm] 82
J [mm] 14,0
K [mm] 82,0
L [mm] 46,0
N [mm] 77,0
Q [mm] 9,0
S [mm] 100,0
T [mm] 15
V [mm] 17
W [mm] 8,0
X [mm] 65
Y [mm] 28
Z [mm] 50
AA [mm] 18,0
AB [mm] 14
More Information
Manufacturer Nr. ND 80/60
Manufacturer Fluidics equipment
EAN 4050571523657
Weight 16.000000
HS-Code 84799070
Article authenticity Original product
Condition of article New
