EMC SQN 32/50 SZ. Compact cylinders, double acting, piston 32 mm, stroke 50 mm

E.MC
€3,365.00
Excl. 19% VAT , excl. Shipping Cost
Article
FL-SQN-32/50-SZ

Manufacturer Nr.
SQN 32/50 SZ
Compact cylinders, double acting, piston 32 mm, stroke 50 mm
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price
Materials:
Body: anodized aluminium, piston rod: hard chromium plated steel, seal: NBR

Temperature range:
-10 to +60 °C

Operating pressure:
max. 10 bar

Version:
With Magnetic piston

Cylinder switch type:
D

Advantages:
•outstanding value,
•cylinder switches can be mounted on different sides,
•main mounting dimensions identical to SMC Series CQ2A (CQ2)

Piston diameter [mm] 32
Stroke [mm] 50
H (piston rod thread) M 8
G (compressed air port) G 1/8"
Repair sets SQN 32 REP
A [mm] 40,0
B [mm] 33,0
C [mm] 13
D [mm] 16
E [mm] 45
F [mm] 7,5
J [mm] 4,5
K [mm] 14
L [mm] 7,0
M [mm] 34
N [mm] 5,5
O [mm] 9 (5,5 deep)
P M 6
P1 [mm] 17,0
Q [mm] 10,5
More Information
Manufacturer Nr. SQN 32/50 SZ
Manufacturer E.MC
EAN 4050571638931
Weight 38.000000
HS-Code 84123100
Article authenticity Original product
Condition of article New
