VLP 12. Multi stage ejectors to 70% vacuum, G 3/4", to 750 l/min

Fluidics equipment
€65,461.00
Excl. 19% VAT , excl. Shipping Cost
Article
FL-VLP-12

Manufacturer Nr.
VLP 12
Multi stage ejectors to 70% vacuum, G 3/4", to 750 l/min
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price
Materials:
Body: anodised aluminium, nozzles: brass, seal: neoprene

Temperature range:
-10°C to max. +100°C, (VLP 96 and VLP 128: -20°C to max. +80°C)

Operating pressure:
1 to 7 bar (optimum 4 - 6 bar)

Pressure gauge connection:
G 1/4"

Advantages:
•higher flow,
•low cost,
•maintenance free,
•high suction performance, ideal for porous materials or to evacuate large volumes

Suction performance [l/min] 750
Thread Supply air G 3/8"
Thread vacuum G 3/4"
Thread exhaust air G 3/4"
Air consumption* [l/min] 240 - 340
Silencer** FFSD 34
Vacuum meter MW -163
L [mm] 182
B [mm] 67
H [mm] 67
Evacuation time (1 ltr. to 10%) [s/l] 0,0060
Evacuation time (1 ltr. to 20%) [s/l] 0,0170
Evacuation time (1 ltr. to 30%) [s/l] 0,0320
Evacuation time (1 ltr. to 40%) [s/l] 0,070
Evacuation time (1 ltr. to 50%) [s/l] 0,120
Evacuation time (1 ltr. to 60%) [s/l] 0,170
Evacuation time (1 ltr. to 70%) [s/l] 0,300
Flow at 0% vacuum [l/min] 750
Flow at 10% vacuum [l/min] 617
Flow at 20% vacuum [l/min] 435
Flow at 30% vacuum [l/min] 275
Flow at 40% vacuum [l/min] 195
Flow at 50% vacuum [l/min] 145
Flow at 60% vacuum [l/min] 97
Temperature range [°C] -10 to +100
More Information
Manufacturer Nr. VLP 12
Manufacturer Fluidics equipment
EAN 4050571722609
Weight 15.000000
HS-Code 84141089
Article authenticity Original product
Condition of article New
