ZDFM 100/50 G. Guide cylinder, with slide bearing, pistons 100mm, stroke 50mm

Fluidics equipment
€68,341.00
Excl. 19% VAT , excl. Shipping Cost
Article
FL-ZDFM-100/50-G

Manufacturer Nr.
ZDFM 100/50 G
Guide cylinder, with slide bearing, pistons 100mm,stroke 50mm
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price
Materials:
Body and plate: Anodized aluminium, guide rods: Steel, hard chrome-plated, piston rod: Steel, hard chrome-plated, piston: Aluminium, Gasket: NBR / PUR

Temperature range:
-20 to +80 °C

Operating pressure:
max. 10 bar

Version:
With Magnetic piston

Cylinder switch type:
D, A

Advantages:
•ideal for accepting large transverse loads,
•numerous mounting options

Piston diameter [mm] 100
Stroke [mm] 50
Version with slide bearing
F (compressed air port) G 1/4"
Repair sets ZDFM 100 REP
lateral force permissible [N] 471
permissible torque at the end-plate [Nm] 19,62
A [mm] 16
B [mm] 21,0
C [mm] 35
D [mm] 32
E1 [mm] 190
E2 [mm] 80
E3 [mm] 89,0
F1 [mm] 21,0
F2 [mm] 19
F3 [mm] 40
G1 [mm] 221
G2 [mm] 108
H [mm] 170
H1 [mm] 170
L1 [mm] 66,0
L2 [mm] 84,0
L3 [mm] 105,0
M1 [mm] 224
M2 [mm] 112
N [mm] 62
O1 [mm] 25
O2 [mm] 15
O3 [mm] 200
P1 M 14
P2 M 10
Q [mm] 35
R [mm] 21,0
T1 [mm] 2,0
T2 [mm] 2,0
More Information
Manufacturer Nr. ZDFM 100/50 G
Manufacturer Fluidics equipment
EAN 4050571809973
Weight 9.000000
HS-Code 84123100
Article authenticity Original product
Condition of article New
