Airtec ZDPMK 20/500. ISO 6432 cylinders, double acting, piston 20 mm, stroke 500 mm

Airtec
€7,879.00
Excl. 19% VAT , excl. Shipping Cost
Article
FL-ZDPMK-20/500

Manufacturer Nr.
ZDPMK 20/500
ISO 6432 cylinders, double acting, piston 20 mm, stroke 500 mm
Add to Wish List Add to Compare
main product photo
The product may differ from the illustration
Frequently Bought Together
Total price
Materials:
Head and foot: anodized aluminium, cylinder tube: 1.4301, piston rod: 1.4305 seal: NBR / PUR

Temperature range:
-20°C to +80°C

Operating pressure:
max. 10 bar

Version:
With Magnetic piston

Cylinder switch type:
D in combination with fastening D1, C in combination with fastening C1

Optional:
FKM seals (temperature range: -20°C to max. +150°C, without magnetic piston) -V, ATEX approval Ex II 2GD c T5 T100° -20°C <=Ta<= 80°C -X

Piston diameter [mm] 20
Stroke [mm] 500
Version adjustable end position damping, continuous piston rod
A (piston rod thread) M 8
B (fastening thread) M 22x1,5
G (compressed air port) G 1/8"
A1 [mm] 8
C [mm] 27
D [mm] 16
E [mm] 8
F [mm] 20
G [mm] 95
K [mm] 24
L [mm] 20
M [mm] 131
N [mm] 12
P [mm] 67
CH [mm] 7
More Information
Manufacturer Nr. ZDPMK 20/500
Manufacturer Airtec
EAN 4050571815202
Weight 1.000000
HS-Code 84123100
GPSR manufacturer information AIRTEC Pneumatic GmbH, Westerbachstraße 7, DE-61476 Kronberg, www.airtec.de
Article authenticity Original product
Condition of article New
