Base plate electrode in stainless steel as counter electrode for through and volume resistance measurements. Ø 80 mm, height 20 mm, with 4 mm safety banana plug.

Base Plate Electrode in Stainless Steel for Volume Measurement - A1-ESD EP0204015

Name: Base Plate Electrode in Stainless Steel for Volume Measurement - A1-ESD EP0204015
Brand: A1-ESD
SKU: EP0204015
Price: 68 EUR
Availability: InStock

A1-ESD Original product

Net price (excl. VAT)

€68.00

Excl. 19% VAT , excl. Shipping Cost

Available Fast shipping

Item EP0204015

Manufacturer no. EP0204015

Personal expert advice

Brand new Specialist dealer since 2009 Original product Worldwide shipping

Product data

Manufacturer no.EP0204015

ConditionNew

Article

EP0204015

Frequently Bought Together

This Item: Base Plate Electrode in Stainless Steel for Volume Measurement - A1-ESD EP0204015
€68.00
Excl. 19% VAT , excl. Shipping Cost
Electrostatic sensor ±0.4 kV, 10 to 50 mm - SMC IZD10-110
€395.85
Excl. 19% VAT , excl. Shipping Cost
Digital Display Unit IZE113 with 4-20 mA Analog Output - A1-ESD EP0202004
€106.75
Excl. 19% VAT , excl. Shipping Cost

Total price

Details

This stainless steel base plate electrode serves as a counter electrode for through and volume resistance measurements. It is placed under the test material and connected to the meter via a 4 mm safety banana plug.

Benefits

Corrosion resistant stainless steel for long service life
Defined contact area for repeatable volume measurement
4 mm safety banana plug for a secure connection

Technical data

Material: stainless steel
Diameter: 80 mm
Height: 20 mm
Weight: 720 g
Connection: 4 mm safety banana plug

Application

Counter electrode for through and volume resistance measurements on ESD materials within the EPA.

Standards

Supports measurements to DIN IEC 61340-4-1 as part of the ESD control programme to IEC 61340-5-1.

Information

More Information
Norm	IEC 61340-5-1, IEC 61340-4-1
Execution	ESD (antistatic)
Manufacturer Nr.	EP0204015
Manufacturer	A1-ESD
Weight	0.720000
Height	20
Width	80
Sales unit	1 Stück
Article authenticity	Original product
Condition of article	New
